| 1 | 69600-06G00 | CYLINDER ASSY, RR MASTER Includes Item(s) 2 - 9 | 1 шт. | — | |
|
| 2 | 69600-34820 | PISTON/CUP SET | 1 шт. | — | |
|
| 3 | 69691-00A00 | BOOT | 1 шт. | — | |
|
| 4 | 69692-19A00 | YOKE | 1 шт. | — | |
|
| 5 | 69670-03G00 | ROD, PUSH | 1 шт. | — | |
|
| 6 | 69693-05A00 | NUT | 2 шт. | — | |
|
| 7 | 69672-00B20 | CONNECTOR | 1 шт. | — | |
|
| 8 | 69686-34200 | .O-RING | 1 шт. | — | |
|
| 9 | 69674-00B20 | CIRCLIP | 1 шт. | — | |
|
| 10 | 09139-06029 | BOLT (6X25) | 2 шт. | — | |
|
| 11 | 09200-06068 | PIN | 1 шт. | — | |
|
| 12 | 08322-0106B | WASHER | 1 шт. | — | |
|
| 13 | 04111-2015A | COTTER PIN | 1 шт. | — | |
|
| 14 | 69740-01D02 | TANK ASSY, REAR RESERVOIR Includes Item(s) 15 - 17 | 1 шт. | — | |
|
| 15 | 59667-04700 | DIAPHRAGM | 1 шт. | — | |
|
| 16 | 59669-05D00 | CAP | 1 шт. | — | |
|
| 17 | 69689-04A00 | SCREW | 2 шт. | — | |
|
| 18 | 01547-0612A | BOLT | 1 шт. | — | |
|
| 19 | 69750-27G10 | BRACKET, RR RESERVOIR TANK | 1 шт. | — | |
|
| 20 | 01547-0612A | BOLT | 1 шт. | — | |
|
| 21 | 69730-27G00 | HOSE, RESERVOIR TANK | 1 шт. | — | |
|
| 22 | 09401-13417 | CLIP, UPPER | 1 шт. | — | |
|
| 23 | 09401-12404 | CLIP, LOWER | 1 шт. | — | |
|
| 24 | 69200-27G00 | HOSE ASSY, RR BRAKE NO.1 | 1 шт. | — | |
|
| 25 | 69400-27G00 | HOSE ASSY, RR BRAKE NO.2 | 1 шт. | — | |
|
| 26 | 09360-10062 | BOLT, CALIPER (10X1.25X22) | 2 шт. | — | |
|
| 27 | 09161-10009 | WASHER (10X15X1.5) | 4 шт. | — | |
|
| 28 | 61196-27G00 | GUIDE, BRAKE HOSE | 0 шт. | — | |
|
| 29 | 61196-06G00 | GUIDE, REAR BRAKE HOSE FRONT | 1 шт. | — | |
|
| 30 | 02142-0510A | SCREW | 2 шт. | — | |
|
| 31 | 69266-27G00 | CLAMP, RR BRAKE HOSE NO.2 | 0 шт. | — | |
|
| 32 | 01547-0612A | BOLT | 1 шт. | — | |
|
| 33 | 69641-06G00 | COVER, RR MASTER CYLINDER | 1 шт. | — | |
|
