| 1 | 64111-06G10-019 | WHEEL, REAR (17M/CXMT4.00) (BLACK) MODEL K7/K8 MODEL K9 FOR YAY/YME | 1 шт. | — | |
|
| 2 | 64111-06G10-YD8 | WHEEL, REAR (17M/CXMT4.00) (SILVER) MODEL K9 FOR YHG/YPA | 1 шт. | — | |
|
| 3 | 69211-06G00 | DISC,REAR BRAKE | 1 шт. | — | |
|
| 4 | 09106-08160 | BOLT | 4 шт. | — | |
|
| 5 | 64741-10F00 | SPACER, RR AXLE RH | 1 шт. | — | |
|
| 6 | 64610-35F10 | DRUM, REAR SPROCKET | 1 шт. | — | |
|
| 7 | 64651-35F10 | ABSORBER, RR HUB SHOCK | 5 шт. | — | |
|
| 8 | 64711-03F10 | AXLE, REAR | 1 шт. | — | |
|
| 9 | 64733-06G00 | RETAINER, RR SPROCKET DRUM | 1 шт. | — | |
|
| 10 | 64751-27G00 | SPACER, RR AXLE LH | 1 шт. | — | |
|
| 11 | 08314-40187 | NUT | 1 шт. | — | |
|
| 12 | 09160-18030 | WASHER, RR AXLE NUT | 1 шт. | — | |
|
| 13 | 04111-4035A | PIN, RR AXLE COTTER | 1 шт. | — | |
|
| 14 | 09180-20112 | SPACER, REAR HUB BEARING | 1 шт. | — | |
|
| 15 | 09262-32007 | BEARING (32X65X17) | 1 шт. | — | |
|
| 16 | 09285-39001 | OIL SEAL (39X65X7) | 1 шт. | — | |
|
| 17 | 08123-62047 | BEARING (20X47X14) | 2 шт. | — | |
|
| 18 | 09285-28001 | SEAL, DUST | 1 шт. | — | |
|
| 19 | 64511-27G00 | SPROCKET, RR (47T-525) | 1 шт. | — | |
|
| 20 | 08319-3110A | NUT | 5 шт. | — | |
|
| 21 | 65110-06G10 | TIRE, REAR, 150/70R17M/C 69H (BRIDGESTONE) TRAIL WING 152 RADIAL F | 1 шт. | — | |
|
| 22 | 43130-24A00 | VALVE ASSY,WHEEL RIM (TR412) | 1 шт. | — | |
|
| 23 | 43222-73H10 | BALANCER, WHEEL NO.1 | 1 шт. | — | |
|
| 24 | 43224-73H10 | BALANCER, WHEEL NO.2 | 1 шт. | — | |
|
| 25 | 43226-73H10 | BALANCER, WHEEL NO.3 | 1 шт. | — | |
|
