| 1 | 30401-KF0-010 | CUSHION, IGNITION CONTROL MODULE (CDI) | 1 шт. | — | |
|
| 2 | 30510-K33-D01 | COIL, IGNITION | 1 шт. | — | |
|
| 3 | 30520-GFM-900 | SPACER, IGNITION COIL | 2 шт. | — | |
|
| 4 | 30700-MGZ-J01 | CAP ASSY., NOISE SUPPRESSOR | 1 шт. | — | |
|
| 5 | 31600-KVK-901 | RECTIFIER ASSY., REGULATOR | 1 шт. | — | |
|
| 6 | 31730-MAS-601 | DIODE ASSY., THREE WAY (SUMITOMO) | 1 шт. | — | |
|
| 7 | 32100-K33-G50 | WIRE HARNESS | 1 шт. | — | |
|
| 8 | 32146-S84-003 | CONNECTOR, DIODE (2P) (3A) | 1 шт. | — | |
|
| 9 | 32406-KAZ-010 | COVER, STARTER MAGNETIC TERMINAL | 1 шт. | — | |
|
| 10 | 32606-GEV-761 | CAP, DUMMY (4P) (RED) (Honda Code 7679160) | 1 шт. | — | |
|
| 11 | 33714-KL3-620 | RUBBER, TAILLIGHT BRACKET | 2 шт. | — | |
|
| 12 | 35160-MGS-D31 | SENSOR ASSY., BANK ANGLE | 1 шт. | — | |
|
| 13 | 36037-657-000 | GROMMET A, TUBE | 2 шт. | — | |
|
| 14 | 36043-657-000 | GROMMET, WIRE HARNESS | 2 шт. | — | |
|
| 15 | 38110-KYJ-901 | HORN (HIGH) | 1 шт. | — | |
|
| 16 | 38117-KFE-701 | COLLAR, HORN SETTING | 1 шт. | — | |
|
| 17 | 38301-KYJ-941 | RELAY, TURN SIGNAL POSITION | 1 шт. | — | |
|
| 18 | 38501-KWN-901 | RELAY, POWER (MICRO ISO 4P) (OMRON) | 3 шт. | — | |
|
| 19 | 38506-KZZ-900 | COVER, RELAY (2P) | 1 шт. | — | |
|
| 20 | 38770-K75-L61 | PGM-FI UNIT | 1 шт. | — | |
|
| 21 | 38771-GFM-900 | SUSPENSION, ENGINE CONTROL UNIT | 1 шт. | — | |
|
| 22 | 50204-KYJ-900 | STAY, IGNITION COIL | 1 шт. | — | |
|
| 23 | 50214-KYJ-900 | COLLAR, IGNITION COIL MOUNTING | 2 шт. | — | |
|
| 24 | 64535-MFJ-D00 | RUBBER, SIDE COVER | 2 шт. | — | |
|
| 25 | 90129-MGZ-J00 | COLLAR, BANK ANGLE SENSOR | 2 шт. | — | |
|
| 26 | 90651-KV6-003 | BAND, WIRE (165MM) (BLACK) | 1 шт. | — | |
|
| 27 | 91536-STK-003 | CLIP, RELAY HOLDER (NATURAL) | 1 шт. | — | |
|
| 28 | 91556-SP0-003 | CLIP, CONNECTOR (BROWN) | 1 шт. | — | |
|
| 29 | 92101-06020-4J | BOLT, HEX. (6X20) | 2 шт. | — | |
|
| 30 | 94050-06080 | NUT, FLANGE (6MM) | 2 шт. | — | |
|
| 31 | 94103-06800 | WASHER, PLAIN (6MM) | 2 шт. | — | |
|
| 32 | 95701-06016-00 | BOLT, FLANGE (6X16) (Honda Code 2410892) | 1 шт. | — | |
|
| 33 | 95701-06016-08 | BOLT, FLANGE (6X16) | 2 шт. | — | |
|
| 34 | 95701-06022-00 | BOLT, FLANGE (6X22) | 2 шт. | — | |
|
| 35 | 95701-06022-08 | BOLT, FLANGE (6X22) | 2 шт. | — | |
|
| 36 | 98200-41000 | FUSE, MINI (10A) | 6 шт. | — | |
|
| 37 | 98200-41500 | FUSE, MINI (15A) (Honda Code 4853438) | 2 шт. | — | |
|
| 38 | 98200-43000 | FUSE, MINI (30A) (Honda Code 5359666) | 2 шт. | — | |
|
