| 1 | 18150-MKC-A00 | PIPE, R. EX. | 1 шт. | — | |
|
| 2 | 18151-MKC-A00 | COVER, R. FR. EX. | 1 шт. | — | |
|
| 3 | 18152-MKC-A00 | COVER, L. FR. EX. | 1 шт. | — | |
|
| 4 | 18153-MKC-A00 | COVER, R. EX. MIDDLE | 1 шт. | — | |
|
| 5 | 18154-MKC-A00 | COVER, L. EX. MIDDLE | 1 шт. | — | |
|
| 6 | 18155-MKC-A00 | COVER, R. RR. EX. | 1 шт. | — | |
|
| 7 | 18156-MKC-A00 | COVER, L. RR. EX. | 1 шт. | — | |
|
| 8 | 18250-MKC-A00 | PIPE, L. EX. | 1 шт. | — | |
|
| 9 | 18291-MN4-920 | GASKET, EX. PIPE | 6 шт. | — | |
|
| 10 | 18293-MCA-A20 | RUBBER, PROTECTOR GASKET | 12 шт. | — | |
|
| 11 | 18293-MJP-G50 | RUBBER, PROTECTOR GASKET | 8 шт. | — | |
|
| 12 | 18300-MKC-A00 | MUFFLER, R. EX. | 1 шт. | — | |
|
| 13 | 18315-MKC-A01 | COVER, R. MUFFLER | 1 шт. | — | |
|
| 14 | 18325-MKC-A00 | COVER, R. MUFFLER (INNER) | 1 шт. | — | |
|
| 15 | 18345-MBT-610 | RUBBER, PROTECTOR MOUNTING | 10 шт. | — | |
|
| 16 | 18353-MKC-A00 | COVER, R. EX. PIPE | 1 шт. | — | |
|
| 17 | 18354-MKC-A00 | COVER, L. EX. PIPE | 1 шт. | — | |
|
| 18 | 18355-MKC-A00 | COVER, R. SADDLEBAG GUARD | 1 шт. | — | |
|
| 19 | 18374-MN1-670 | BAND, L. EX. PIPE | 1 шт. | — | |
|
| 20 | 18375-MKC-A00 | BAND, R. MUFFLER | 1 шт. | — | |
|
| 21 | 18376-MKC-A00 | BAND, L. MUFFLER | 1 шт. | — | |
|
| 22 | 18391-MB0-891 | GASKET, MUFFLER | 1 шт. | — | |
|
| 23 | 18392-MG7-750 | GASKET, RR. MUFFLER | 2 шт. | — | |
|
| 24 | 18400-MKC-A00 | MUFFLER, L. EX. | 1 шт. | — | |
|
| 25 | 18415-MKC-A01 | COVER, L. MUFFLER | 1 шт. | — | |
|
| 26 | 18421-MKC-A00 | RUBBER, EX. PIPE MOUNTING | 2 шт. | — | |
|
| 27 | 18422-MKC-A00 | RUBBER, MUFFLER MOUNTING | 2 шт. | — | |
|
| 28 | 18423-MFJ-D00 | COLLAR, EX. PIPE MOUNTING | 4 шт. | — | |
|
| 29 | 18425-MKC-A00 | COVER, L. MUFFLER (INNER) | 1 шт. | — | |
|
| 30 | 18443-MCW-D60 | RUBBER, PROTECTOR | 4 шт. | — | |
|
| 31 | 18455-MKC-A00 | COVER, L. SADDLEBAG GUARD | 1 шт. | — | |
|
| 32 | 19509-MM5-003 | CLAMP, R. RADIATOR HOSE | 6 шт. | — | |
|
| 33 | 36531-MKC-A01 | SENSOR, OXYGEN (#1-3-5) | 1 шт. | — | |
|
| 34 | 36532-MKC-A01 | SENSOR, OXYGEN (#2-4-6) | 1 шт. | — | |
|
| 35 | 50524-MN8-000 | RUBBER, STAND STOPPER | 1 шт. | — | |
|
| 36 | 90102-MKC-A00 | BOLT, FLANGE (8X40) | 4 шт. | — | |
|
| 37 | 90106-MKC-A00 | SCREW, PAN (6X12) | 10 шт. | — | |
|
| 38 | 90304-HB3-771 | NUT, SPECIAL (6MM) | 12 шт. | — | |
|
| 39 | 90507-MKC-A00 | WASHER (8.5X38) | 4 шт. | — | |
|
| 40 | 90653-HC4-900 | CLIP, SPLASH GUARD (Honda Code 3795994) | 2 шт. | — | |
|
| 41 | 96400-08035-04 | BOLT, FLANGE (8X35) | 3 шт. | — | |
|
