| 1 | 51400-K33-305 | FORK ASSY., R. FR. (COO) (SHOWA) | 1 шт. | — | |
|
| 2 | 51400-K33-651 | FORK ASSY., R. FR. (SHOWA) | 1 шт. | — | |
|
| 3 | 51401-K33-701 | SPRING, FR. FORK | 2 шт. | — | |
|
| 4 | 51402-K33-701 | COLLAR, SPRING | 2 шт. | — | |
|
| 5 | 51403-ME4-003 | PLATE, SPRING JOINT | 2 шт. | — | |
|
| 6 | 51410-K33-701 | PIPE, FR. FORK | 2 шт. | — | |
|
| 7 | 51411-MG1-003 | SPRING, FR. FORK REBOUND | 2 шт. | — | |
|
| 8 | 51412-461-003 | RING, BACK-UP | 2 шт. | — | |
|
| 9 | 51414-KFB-901 | BUSH, GUIDE | 2 шт. | — | |
|
| 10 | 51415-KFB-901 | BUSH, SLIDER | 2 шт. | — | |
|
| 11 | 51420-KYJ-921 | CASE, R. (LOWER) | 1 шт. | — | |
|
| 12 | 51432-KAZ-003 | PIECE, OIL LOCK | 2 шт. | — | |
|
| 13 | 51437-ML7-691 | RING, PISTON | 2 шт. | — | |
|
| 14 | 51440-KYJ-901 | PIPE, SEAT | 2 шт. | — | |
|
| 15 | 51447-KR6-003 | RING, OIL SEAL STOPPER | 2 шт. | — | |
|
| 16 | 51450-KAS-901 | BOLT, FR. FORK | 2 шт. | — | |
|
| 17 | 51490-KWL-003 | SEAL SET, FR. FORK | 2 шт. | — | |
|
| 18 | 51500-K33-305 | FORK ASSY., L. FR. (COO) (SHOWA) | 1 шт. | — | |
|
| 19 | 51500-K33-651 | FORK ASSY., L. FR. (SHOWA) | 1 шт. | — | |
|
| 20 | 51520-KYJ-921 | CASE, L. (LOWER) | 1 шт. | — | |
|
| 21 | 90109-MR7-000 | BOLT, FLANGE (8X45) | 1 шт. | — | |
|
| 22 | 90116-KV3-701 | BOLT, SOCKET (8MM) (SHOWA) | 2 шт. | — | |
|
| 23 | 90544-283-000 | WASHER, SPECIAL (8MM) (SHOWA) | 2 шт. | — | |
|
| 24 | 91254-KAZ-003 | DUST SEAL DUST SEAL, FR. FORK | 2 шт. | — | |
|
| 25 | 91357-ME4-003 | O-RING (27.7X3.5) | 2 шт. | — | |
|
