| 1 | 17245-107-010 | RUBBER, AIR CLEANER HOUSING MOUNTING | 2 шт. | — | |
|
| 2 | 33741-KPL-902 | REFLECTOR, REFLEX | 1 шт. | — | |
|
| 3 | 50240-K87-A00ZA | FRAME ASSY., R. RR. *NH105* (MAT BLACK) | 1 шт. | — | |
|
| 4 | 50242-K87-A00 | RUBBER, RR. FRAME | 10 шт. | — | |
|
| 5 | 50245-K87-A00ZA | FRAME ASSY., L. RR. *NH105* (MAT BLACK) | 1 шт. | — | |
|
| 6 | 50327-K87-A00 | BOX B, BATTERY | 1 шт. | — | |
|
| 7 | 50351-K87-A00 | STAY, REGULATOR | 1 шт. | — | |
|
| 8 | 50352-GS6-000 | RUBBER, LINK STOPPER | 2 шт. | — | |
|
| 9 | 50356-K87-A00 | RUBBER, REGULATOR STAY MOUNTING | 2 шт. | — | |
|
| 10 | 61104-428-010 | COLLAR, FR. FENDER (WHITE) (FOR RR.) | 4 шт. | — | |
|
| 11 | 61104-428-730 | COLLAR, FR. FENDER (BLACK) (FOR RR.) | 4 шт. | — | |
|
| 12 | 61304-415-000 | RUBBER, HEADLIGHT CASE MOUNTING | 2 шт. | — | |
|
| 13 | 77206-MJ0-000 | RUBBER, SEAT SETTING | 2 шт. | — | |
|
| 14 | 80101-K87-A00 | FENDER A, R. RR. | 1 шт. | — | |
|
| 15 | 80102-K87-A00 | RUBBER, RR. FENDER | 5 шт. | — | |
|
| 16 | 80103-K87-A00 | RUBBER, TAILLIGHT CODE | 1 шт. | — | |
|
| 17 | 80106-K87-A00 | FENDER A, L. RR. | 1 шт. | — | |
|
| 18 | 80110-MKG-A10ZA | FENDER SET, RR. (TYPE4) (WL) | 1 шт. | — | |
|
| 19 | 80110-MKG-A10ZB | FENDER SET, RR. (TYPE3) (WL) | 1 шт. | — | |
|
| 20 | 80110-MKG-A10ZC | FENDER SET, RR. (TYPE2) (WL) | 1 шт. | — | |
|
| 21 | 80110-MKG-A10ZD | FENDER SET, RR. (TYPE1) (WL) | 1 шт. | — | |
|
| 22 | 80115-K87-A00 | STAY, RR. FENDER | 1 шт. | — | |
|
| 23 | 80116-K87-A00 | COLLAR, TAILLIGHT | 2 шт. | — | |
|
| 24 | 80128-K87-A00 | STAY, TAILLIGHT | 1 шт. | — | |
|
| 25 | 80130-K87-A00 | PLATE ASSY., RR. FRAME | 1 шт. | — | |
|
| 26 | 80350-K87-A00 | COVER, TAILLIGHT | 1 шт. | — | |
|
| 27 | 84700-K87-A00 | BRACKET, NUMBER PLATE | 1 шт. | — | |
|
| 28 | 90102-KTM-D20 | BOLT, FLANGE (6X14) | 2 шт. | — | |
|
| 29 | 90108-K87-A00 | BOLT, SOCKET SPECIAL (8X18) | 6 шт. | — | |
|
| 30 | 90109-K87-A00 | BOLT, SOCKET SPECIAL (8X12) | 2 шт. | — | |
|
| 31 | 90114-KPH-700 | SCREW, SPECIAL (5X11) | 5 шт. | — | |
|
| 32 | 90116-SP0-003 | CLIP, BUMPER SEAL | 3 шт. | — | |
|
| 33 | 90118-MGZ-D80 | SCREW, PAN (6X14) | 1 шт. | — | |
|
| 34 | 90201-428-900 | NUT, CAP (L. SIDE ONLY) | 2 шт. | — | |
|
| 35 | 90301-KWN-901 | NUT, U (5MM) | 1 шт. | — | |
|
| 36 | 90899-422-610 | PLUG, CONE TYPE | 1 шт. | — | |
|
| 37 | 93404-06028-00 | BOLT-WASHER (6X28) | 2 шт. | — | |
|
| 38 | 94050-06000 | NUT, FLANGE (6MM) | 2 шт. | — | |
|
| 39 | 95701-06022-00 | BOLT, FLANGE (6X22) | 2 шт. | — | |
|
| 40 | 95701-10028-00 | BOLT, FLANGE (10X28) | 4 шт. | — | |
|
| 41 | 96001-06028-00 | BOLT, FLANGE (6X28) | 2 шт. | — | |
|
