| 1 | 18309-GN3-670 | COLLAR B, MUFFLER STAY | 2 шт. | — | |
|
| 2 | 50100-MFR-770ZH | FRAME *NH1* (BLACK) | 1 шт. | — | |
|
| 3 | 50165-MFR-670 | BRACKET, HELMET HOLDER | 1 шт. | — | |
|
| 4 | 50202-MFR-670 | PLATE, ENGINE HANGER (LOWER) | 1 шт. | — | |
|
| 5 | 50203-MFR-670 | PLATE, ENGINE HANGER CENTER | 1 шт. | — | |
|
| 6 | 50204-MFR-670 | PLATE, RR. ENGINE MOUNT (LOWER) (RH) | 1 шт. | — | |
|
| 7 | 50207-MFR-670 | PLATE, R. RR. ENGINE HANGER (UPPER) | 1 шт. | — | |
|
| 8 | 50208-MFR-670 | PLATE, L. RR. ENGINE HANGER (UPPER) | 1 шт. | — | |
|
| 9 | 50210-MFR-670 | PLATE, PIVOT MOUNT | 1 шт. | — | |
|
| 10 | 50220-MFR-670 | PIPE, FR. CROSS | 1 шт. | — | |
|
| 11 | 50221-MFR-670 | COLLAR, ENGINE HANGER (24X41.5) | 2 шт. | — | |
|
| 12 | 50223-MFR-670 | COLLAR, ENGINE HANGER (24X32) | 1 шт. | — | |
|
| 13 | 50232-MFR-670 | COLLAR A, FR. CROSS PIPE | 2 шт. | — | |
|
| 14 | 50302-HN8-003 | RUBBER C, MOUNTING | 2 шт. | — | |
|
| 15 | 50305-HN8-003 | RUBBER, ENGINE HEAD MOUNTING | 1 шт. | — | |
|
| 16 | 50352-428-000 | RUBBER A, STOPPER | 4 шт. | — | |
|
| 17 | 50710-GCN-003 | HOLDER ASSY., HELMET (HONDALOCK) | 1 шт. | — | |
|
| 18 | 50710-GCN-305 | HOLDER ASSY., HELMET (COO) | 1 шт. | — | |
|
| 19 | 53600-MFR-AC0 | LOCK SET, HANDLEBAR | 1 шт. | — | |
|
| 20 | 53600-404-611 | LOCK, HANDLEBAR | 1 шт. | — | |
|
| 21 | 53603-051-000 | RIVET (4.1MM) | 1 шт. | — | |
|
| 22 | 53604-098-940 | WASHER (4.5MM) | 1 шт. | — | |
|
| 23 | 53604-098-941 | WASHER (4.5MM) | 1 шт. | — | |
|
| 24 | 90105-KEB-620 | BOLT, ONE-WAY (6X12) | 1 шт. | — | |
|
| 25 | 90110-MFR-670 | BOLT, FLANGE (10X148) | 1 шт. | — | |
|
| 26 | 90111-MFR-670 | BOLT, FLANGE (10X151) | 1 шт. | — | |
|
| 27 | 90112-MFR-670 | BOLT, FLANGE (10X235.5) | 1 шт. | — | |
|
| 28 | 90117-MFR-670 | BOLT, FLANGE (10X212) | 1 шт. | — | |
|
| 29 | 90118-MR1-000 | SCREW, PAN (6X14) | 4 шт. | — | |
|
| 30 | 90130-MEW-D20 | BOLT, TORX (6X13) | 2 шт. | — | |
|
| 31 | 90154-MFR-670 | BOLT, FLANGE (10X52) | 1 шт. | — | |
|
| 32 | 90155-MFR-670 | BOLT, FLANGE (10X66) | 1 шт. | — | |
|
| 33 | 90312-MB0-700 | CAP, R. LOCK NUT (BOTH SIDES) | 1 шт. | — | |
|
| 34 | 90690-GHB-641 | CLIP, CABLE (10MM) CLIP, CABLE (8MM) | 2 шт. | — | |
|
| 35 | 90690-GHB-651 | CLIP, CABLE (15MM) | 2 шт. | — | |
|
| 36 | 90690-GHB-661 | CLIP, CABLE (20MM) | 1 шт. | — | |
|
| 37 | 90852-446-630 | PLUG, HOLE | 4 шт. | — | |
|
| 38 | 90303-428-900 | NUT, FLANGE (10MM) | 7 шт. | — | |
|
| 39 | 94050-10070 | NUT, FLANGE (10MM) | 7 шт. | — | |
|
| 40 | 95701-06028-07 | BOLT, FLANGE (6X28) | 2 шт. | — | |
|
| 41 | 95701-08012-07 | BOLT, FLANGE (8X12) | 4 шт. | — | |
|
| 42 | 95701-08020-07 | BOLT, FLANGE (8X20) | 2 шт. | — | |
|
| 43 | 95701-08025-07 | BOLT, FLANGE (8X25) | 2 шт. | — | |
|
| 44 | 95701-08028-07 | BOLT, FLANGE (8X28) | 2 шт. | — | |
|
| 45 | 95701-08030-07 | BOLT, FLANGE (8X30) | 4 шт. | — | |
|
| 46 | 95701-10025-07 | BOLT, FLANGE (10X25) | 2 шт. | — | |
|
| 47 | 95701-10032-07 | BOLT, FLANGE (10X32) | 2 шт. | — | |
|
| 48 | 95701-10065-07 | BOLT, FLANGE (10X65) | 1 шт. | — | |
|
