| 1 | 15010-MCE-H51 | FILTER SET, OIL (Honda Code 8624900) (Optional). | 1 шт. | — | |
|
| 1 | 15010-MKR-305 | FILTER SET, OIL (Optional). | 1 шт. | — | |
|
| 2 | 15100-MFE-A41 | PUMP ASSY., OIL | 1 шт. | — | |
|
| 3 | 15134-MEW-920 | SPROCKET, OIL PUMP DRIVEN (27T) | 1 шт. | — | |
|
| 4 | 15141-MEG-A21 | CHAIN, OIL PUMP DRIVE (70L) (DAIDO) | 1 шт. | — | |
|
| 5 | 15153-MZ6-000 | STRAINER, OIL | 1 шт. | — | |
|
| 6 | 15154-425-000 | GASKET, OIL STRAINER | 1 шт. | — | |
|
| 7 | 15155-300-000 | COLLAR, O-RING | 2 шт. | — | |
|
| 8 | 15220-MFE-A41 | VALVE ASSY., RELIEF | 1 шт. | — | |
|
| 9 | 15410-MFJ-D01 | FILTER, OIL (TOYO ROKI) (Honda Code 8597650) Use up to Engine SN 2517425. | 1 шт. | — | |
|
| 9 | 15410-MFJ-D02 | FILTER, OIL (WAKO FILTER) | 1 шт. | — | |
|
| 10 | 15510-MY1-000 | PIPE, OIL | 1 шт. | — | |
|
| 11 | 90009-MZ8-H00 | BOLT, FLANGE SOCKET (6X14) | 1 шт. | — | |
|
| 12 | 90019-MB0-000 | BOSS, OIL FILTER (Honda Code 1243435) | 1 шт. | — | |
|
| 13 | 90488-MB0-000 | WASHER (6X2.3) | 1 шт. | — | |
|
| 14 | 91302-MGS-D30 | O-RING (14.7X2.2) | 1 шт. | — | |
|
| 15 | 91303-KF0-003 | O-RING (14.8X2.4) (ARAI) | 2 шт. | — | |
|
| 16 | 91315-MF5-003 | OIL SEAL, PIPE | 2 шт. | — | |
|
| 17 | 91319-300-000 | O-RING (13X2.5) | 1 шт. | — | |
|
| 18 | 94301-08140 | PIN, DOWEL (8X14) (Honda Code 0069310) | 1 шт. | — | |
|
| 19 | 95701-06028-00 | BOLT, FLANGE (6X28) | 1 шт. | — | |
|
| 20 | 95701-06045-00 | BOLT, FLANGE (6X45) | 2 шт. | — | |
|
| 20 | 95701-06045-07 | BOLT, FLANGE (6X45) BOLT, FLANGE (6X60) | 2 шт. | — | |
|
