| 1 | 11380-MEG-A60 | STAY, L. RR. COVER | 1 шт. | — | |
|
| 2 | 21100-MEG-000 | CASE ASSY., SIDE GEAR | 1 шт. | — | |
|
| 3 | 21200-MEG-000 | CASE, SIDE GEAR | 1 шт. | — | |
|
| 4 | 21215-ME9-000 | ORIFICE, SIDE GEAR CASE | 1 шт. | — | |
|
| 5 | 21281-MS9-750 | HOLDER, FINAL DRIVESHAFT BEARING | 1 шт. | — | |
|
| 6 | 21309-MEG-000 | SHIM, FINAL DRIVESHAFT (0.30) | 1 шт. | — | |
|
| 7 | 21310-MEG-000 | SHIM, FINAL DRIVESHAFT (0.35) | 1 шт. | — | |
|
| 8 | 21311-MEG-000 | SHIM, FINAL DRIVESHAFT (0.40) | 1 шт. | — | |
|
| 9 | 21312-MEG-000 | SHIM, FINAL DRIVESHAFT (0.45) | 1 шт. | — | |
|
| 10 | 21313-MEG-000 | SHIM, FINAL DRIVESHAFT (0.50) | 1 шт. | — | |
|
| 11 | 21314-MEG-000 | SHIM, FINAL DRIVESHAFT (0.55) | 1 шт. | — | |
|
| 12 | 21315-MEG-000 | SHIM, FINAL DRIVESHAFT (0.60) | 1 шт. | — | |
|
| 13 | 21316-MEG-000 | SHIM, FINAL DRIVESHAFT (0.65) | 1 шт. | — | |
|
| 14 | 21317-MEG-000 | SHIM, FINAL DRIVESHAFT (0.70) | 1 шт. | — | |
|
| 15 | 21318-MEG-000 | SHIM, FINAL DRIVESHAFT (0.75) | 1 шт. | — | |
|
| 16 | 21371-MS9-000 | HOLDER, CROSS SHAFT BEARING | 1 шт. | — | |
|
| 17 | 21377-MB0-770 | SHIM, CROSS SHAFT (0.20) | 1 шт. | — | |
|
| 18 | 21378-MB0-770 | SHIM, CROSS SHAFT (0.25) | 1 шт. | — | |
|
| 19 | 21379-MB0-770 | SHIM, CROSS SHAFT (0.30) | 1 шт. | — | |
|
| 20 | 21380-MB0-770 | SHIM, CROSS SHAFT (0.35) | 1 шт. | — | |
|
| 21 | 21381-MB0-770 | SHIM, CROSS SHAFT (0.40) | 1 шт. | — | |
|
| 22 | 21382-MB0-770 | SHIM, CROSS SHAFT (0.45) | 1 шт. | — | |
|
| 23 | 21383-MB0-770 | SHIM, CROSS SHAFT (0.50) | 1 шт. | — | |
|
| 24 | 21384-MB0-770 | SHIM, CROSS SHAFT (0.55) | 1 шт. | — | |
|
| 25 | 21385-MB0-770 | SHIM, CROSS SHAFT (0.60) | 1 шт. | — | |
|
| 26 | 23200-MEG-000 | SHAFT SET, FINAL DRIVE | 1 шт. | — | |
|
| 27 | 23721-ME9-000 | LIFTER, DAMPER | 1 шт. | — | |
|
| 28 | 23726-MBL-610 | GEAR, DAMPER SHAFT (32T) | 1 шт. | — | |
|
| 29 | 23732-MS9-750 | SPRING, DAMPER | 1 шт. | — | |
|
| 30 | 23733-MS9-000 | COLLAR (20X24X19.8) | 1 шт. | — | |
|
| 31 | 37700-MFE-641 | SENSOR ASSY., SPEED | 1 шт. | — | |
|
| 32 | 83551-GE2-000 | GROMMET, AIR CLEANER HOUSING | 1 шт. | — | |
|
| 33 | 90029-MBL-610 | BOLT, UBS (8X65) | 1 шт. | — | |
|
| 34 | 90030-MBL-610 | BOLT, UBS (8X110) | 2 шт. | — | |
|
| 35 | 90037-ME9-000 | BOLT, SPECIAL (10MM) | 1 шт. | — | |
|
| 36 | 90063-MB0-003 | BOLT, UBS (8X60) | 1 шт. | — | |
|
| 37 | 90065-HA8-680 | BOLT, UBS (8X45) | 1 шт. | — | |
|
| 38 | 90241-MB0-000 | NUT, LOCK (30MM) | 2 шт. | — | |
|
| 39 | 90242-MB0-000 | NUT, LOCK (64MM) | 2 шт. | — | |
|
| 40 | 90409-952-000 | WASHER (10MM) | 1 шт. | — | |
|
| 41 | 90451-704-000 | WASHER A, THRUST (20MM) | 1 шт. | — | |
|
| 42 | 90602-463-000 | CIRCLIP (OUTER) (28MM) | 1 шт. | — | |
|
| 43 | 90690-GHB-651 | CLIP, CABLE (15MM) | 1 шт. | — | |
|
| 44 | 90701-MG8-000 | PIN, DOWEL (10X24) | 1 шт. | — | |
|
| 45 | 91008-300-008 | BEARING, BALL (5206) (TOYO) | 1 шт. | — | |
|
| 46 | 91012-MG7-003 | BEARING, RADIAL BALL (5206) | 1 шт. | — | |
|
| 47 | 91011-MB0-003 | BEARING, BALL (6303) (KOYO) | 1 шт. | — | |
|
| 48 | 91011-MB0-004 | BEARING, BALL (6303) (TOYO) | 1 шт. | — | |
|
| 49 | 91012-MG7-003 | BEARING, RADIAL BALL (5206) | 1 шт. | — | |
|
| 50 | 91205-MG7-003 | OIL SEAL (25X66X8.5) (ARAI) | 1 шт. | — | |
|
| 51 | 91301-MS9-003 | O-RING (64X2.5) | 1 шт. | — | |
|
| 52 | 91307-422-000 | O-RING (4.8X1.9) | 2 шт. | — | |
|
| 53 | 91313-MA6-005 | O-RING (4.8X1.9) (NOK) O-RING (7.7X2.3) (ARAI) | 2 шт. | — | |
|
| 54 | 91314-MG7-003 | O-RING (69.5X3) (ARAI) | 2 шт. | — | |
|
| 55 | 91565-SEL-003 | CLIP, CONNECTOR (BLACK) (Honda Code 7386865) | 1 шт. | — | |
|
| 56 | 94520-65120 | CIRCLIP (INNER) (65MM) | 1 шт. | — | |
|
| 57 | 95701-06014-00 | BOLT, FLANGE (6X14) (Honda Code 2410884) | 2 шт. | — | |
|
| 58 | 96100-62040-00 | BEARING, RADIAL BALL (6204) | 1 шт. | — | |
|
| 59 | 96700-08022-17 | BOLT, SOCKET (8X22) | 4 шт. | — | |
|
