| 1 | 40200-MR6-671 | JOINT, YOKE | 1 шт. | — | |
|
| 2 | 40207-MT3-610 | BOOT, JOINT | 1 шт. | — | |
|
| 3 | 40210-MEG-000 | SHAFT ASSY., PROPELLER | 1 шт. | — | |
|
| 4 | 40215-ME9-003 | SPRING, PROPELLER SHAFT | 1 шт. | — | |
|
| 5 | 40221-MB0-000 | RING, STOPPER | 1 шт. | — | |
|
| 6 | 52100-MEG-H10 | SWINGARM ASSY., RR. | 1 шт. | — | |
|
| 7 | 90121-MAM-A60 | BOLT, R. SWINGARM PIVOT (L. SIDE) | 1 шт. | — | |
|
| 8 | 90122-MAM-L40 | BOLT, L. SWINGARM PIVOT (R. SIDE) | 1 шт. | — | |
|
| 9 | 90129-KFG-000 | BOLT, FLANGE (8X32) | 1 шт. | — | |
|
| 10 | 90158-MEG-H10 | BOLT, BRAKE STOPPER | 1 шт. | — | |
|
| 11 | 90308-MEG-000 | NUT, HEX. (10MM) | 4 шт. | — | |
|
| 12 | 90355-469-000 | NUT, SWINGARM PIVOT LOCK | 1 шт. | — | |
|
| 13 | 91066-HA7-672 | BEARING, TAPER ROLLER (17X40X13.25) (KOYO) | 2 шт. | — | |
|
| 14 | 91261-ME9-005 | OIL SEAL (27X43X7) | 1 шт. | — | |
|
