| 1 | 22100-HL4-003 | GEAR, PRIMARY DRIVEN (81T) | 1 шт. | — | |
|
| 2 | 22500-MJP-G81 | CLUTCH ASSY. | 2 шт. | — | |
|
| 3 | 22711-MJP-G80 | PIPE A, FEED | 1 шт. | — | |
|
| 4 | 22712-MJP-G80 | PIPE B, FEED | 1 шт. | — | |
|
| 5 | 22720-MJP-G80 | GUIDE, FEED PIPE | 1 шт. | — | |
|
| 6 | 23103-MJP-G80 | GEAR, PRIMARY DRIVE (43T) | 1 шт. | — | |
|
| 7 | 23104-HL4-000 | SUB-GEAR, PRIMARY (43T) | 1 шт. | — | |
|
| 8 | 23115-MW4-000 | SPRING, PRIMARY DAMPER | 3 шт. | — | |
|
| 9 | 23405-MJP-G80 | GUIDE (30T) | 1 шт. | — | |
|
| 10 | 23406-HL4-000 | GUIDE, SECOND CLUTCH GEAR (30T) | 1 шт. | — | |
|
| 11 | 90089-KAS-900 | BOLT, FLANGE SOCKET (5X14) | 2 шт. | — | |
|
| 12 | 90201-HL4-000 | NUT, LOCK (22MM) | 1 шт. | — | |
|
| 13 | 90403-HL4-000 | WASHER (29.5X50X2) | 2 шт. | — | |
|
| 14 | 90404-HL4-000 | WASHER (22X37X5) | 1 шт. | — | |
|
| 15 | 91302-PA9-003 | O-RING (39.8X2.2) (ARAI) | 1 шт. | — | |
|
| 16 | 91302-RGC-003 | O-RING (35X2.2) | 4 шт. | — | |
|
| 17 | 91308-PY4-003 | O-RING (10.7X1.9) | 1 шт. | — | |
|
| 18 | 91315-PC9-004 | O-RING (6X1.5) (N0K) | 1 шт. | — | |
|
| 19 | 94302-05080 | PIN B, DOWEL (5X8) | 1 шт. | — | |
|
| 19 | 94303-05080 | PIN, DOWEL (5X8) | 1 шт. | — | |
|
