| 1 | 11000-MKF-D40 | CRANKCASE SET | 1 шт. | — | |
|
| 2 | 11206-MFL-000 | ORIFICE | 1 шт. | — | |
|
| 3 | 11207-MFL-000 | ORIFICE (1.1MM) | 1 шт. | — | |
|
| 4 | 12208-PR3-000 | BOLT, SEALING (20MM) | 1 шт. | — | |
|
| 5 | 15330-MFL-000 | PIPE, R. OIL JET | 1 шт. | — | |
|
| 6 | 15340-MFL-000 | PIPE, L. OIL JET | 1 шт. | — | |
|
| 7 | 15350-MFL-000 | PIPE, TRANSMISSION OIL JET | 1 шт. | — | |
|
| 8 | 15351-MFJ-D00 | ORIFICE (1MM) | 1 шт. | — | |
|
| 9 | 11521-MKF-D40 | HOLDER, ANGLE SENSOR | 1 шт. | — | |
|
| 10 | 35500-MJ4-024 | SWITCH ASSY., OIL PRESSURE (DENSO) | 1 шт. | — | |
|
| 11 | 38800-MKF-D41 | SENSOR ASSY., ANGLE | 1 шт. | — | |
|
| 12 | 37700-MFL-761 | SENSOR ASSY., SPEED | 1 шт. | — | |
|
| 13 | 90004-MM5-000 | BOLT, SPECIAL (6X18) | 1 шт. | — | |
|
| 14 | 90010-MEL-000 | BOLT, SOCKET (8X12) | 1 шт. | — | |
|
| 15 | 90011-MFJ-D00 | BOLT, KNOCK (6MM) | 2 шт. | — | |
|
| 16 | 11522-MKF-D40 | GASKET, ANGLE SENSOR HOLDER | 1 шт. | — | |
|
| 17 | 90015-MFL-003 | BOLT, FLANGE (9X105) | 8 шт. | — | |
|
| 18 | 90016-MFL-003 | BOLT, FLANGE (9X126) | 2 шт. | — | |
|
| 19 | 90017-MEL-000 | BOLT, FLANGE (7X60) | 1 шт. | — | |
|
| 20 | 90017-MFL-000 | BOLT, FLANGE (7X50) | 3 шт. | — | |
|
| 21 | 90019-MAT-000 | BOLT, SEALING (8MM) | 1 шт. | — | |
|
| 22 | 90019-MFA-D00 | BOLT, FLANGE (7X40) | 9 шт. | — | |
|
| 23 | 90032-MFL-000 | BOLT, STUD (9X145.5) | 4 шт. | — | |
|
| 25 | 90048-MFL-000 | BOLT, SEALING (22MM) | 1 шт. | — | |
|
| 26 | 90447-KE1-000 | WASHER, SEALING (7MM) | 1 шт. | — | |
|
| 27 | 90463-ML7-000 | WASHER, SEALING (6.5MM) | 1 шт. | — | |
|
| 28 | 90701-MV9-670 | PIN, DOWEL (10X16) (Honda Code 3906971) | 3 шт. | — | |
|
| 29 | 91310-MGE-D01 | O-RING (16.5X2.5) | 1 шт. | — | |
|
| 30 | 91307-422-000 | O-RING (4.8X1.9) | 3 шт. | — | |
|
| 30 | 91313-MA6-005 | O-RING (4.8X1.9) (NOK) O-RING (7.7X2.3) (ARAI) | 3 шт. | — | |
|
| 31 | 32101-MKF-D40 | SUB-HARNESS, ENGINE | 1 шт. | — | |
|
| 33 | 95701-08050-00 | BOLT, FLANGE (8X50) | 1 шт. | — | |
|
| 34 | 95701-08055-07 | BOLT, FLANGE (8X55) | 1 шт. | — | |
|
| 35 | 95701-08080-00 | BOLT, FLANGE (8X80) | 1 шт. | — | |
|
| 36 | 95701-10060-00 | BOLT, FLANGE (10X60) | 1 шт. | — | |
|
| 37 | 32106-MKF-D60 | SUB-HARNESS, SPINDLE | 1 шт. | — | |
|
| 38 | 35600-MKF-D41 | SWITCH ASSY., NEUTRAL | 2 шт. | — | |
|
| 39 | 90006-GHB-700 | BOLT, FLANGE (6X35) (NSHF) | 1 шт. | — | |
|
| 40 | 90012-MKF-D40 | BOLT, KNOCK (6MM) | 1 шт. | — | |
|
| 41 | 90033-MFL-000 | BOLT, STUD (9X134) | 5 шт. | — | |
|
| 41 | 90033-MFL-000 | BOLT, STUD (9X134) | 1 шт. | — | |
|
| 42 | 91320-KE1-000 | PIN, DOWEL (8X7) | 2 шт. | — | |
|
| 43 | 94050-04000 | NUT, FLANGE (4MM) | 2 шт. | — | |
|
| 44 | 90443-MJ6-000 | WASHER, NEUTRAL | 2 шт. | — | |
|
