| 1 | 17357-GE1-670 | JOINT A, BREATHER | 1 шт. | — | |
|
| 2 | 17525-GBC-300 | RUBBER, FUEL TANK | 2 шт. | — | |
|
| 3 | 19010-MKF-D41 | RADIATOR | 1 шт. | — | |
|
| 4 | 19014-KEA-003 | NUT, SETTING (6MM) | 2 шт. | — | |
|
| 5 | 19015-MFL-D21 | SHROUD, R. | 1 шт. | — | |
|
| 6 | 19016-MKF-D41 | SHROUD, L. | 1 шт. | — | |
|
| 7 | 19020-MFA-D01 | FAN, COOLING | 1 шт. | — | |
|
| 8 | 19030-MFL-D21 | MOTOR ASSY., FAN | 1 шт. | — | |
|
| 9 | 19035-MFL-003 | NECK, FILLER | 1 шт. | — | |
|
| 10 | 19037-GEE-710 | CAP, RADIATOR | 1 шт. | — | |
|
| 11 | 19046-PAA-A00 | LABEL, RADIATOR CAP | 1 шт. | — | |
|
| 12 | 19051-KA3-830 | RUBBER, RADIATOR MOUNTING | 3 шт. | — | |
|
| 13 | 19052-MAC-680 | COLLAR, RADIATOR MOUNTING | 1 шт. | — | |
|
| 14 | 19070-MFL-003 | FAN, COOLING | 1 шт. | — | |
|
| 15 | 19080-MKF-D41 | MOTOR ASSY., FAN | 1 шт. | — | |
|
| 16 | 19101-MKF-D40 | TANK, RADIATOR RESERVE | 1 шт. | — | |
|
| 17 | 19106-MFL-000 | TUBE, RESERVE TANK | 1 шт. | — | |
|
| 18 | 19109-KPC-640 | CAP, RESERVE TANK | 1 шт. | — | |
|
| 19 | 19113-MFL-000 | STAY, RADIATOR (LOWER) | 1 шт. | — | |
|
| 20 | 19128-MKF-D40 | GUARD, R. RADIATOR | 1 шт. | — | |
|
| 21 | 19129-MKF-D40 | GUARD, L. RADIATOR | 1 шт. | — | |
|
| 22 | 19502-MFL-000 | HOSE, OIL COOLER | 1 шт. | — | |
|
| 23 | 19503-MKF-D40 | HOSE A, RADIATOR | 1 шт. | — | |
|
| 24 | 19504-KY1-003 | CLAMP, WATER HOSE (25MM) | 2 шт. | — | |
|
| 25 | 19504-MKF-D40 | HOSE, FILLER NECK | 1 шт. | — | |
|
| 26 | 19505-MKF-D40 | HOSE A, WATER | 1 шт. | — | |
|
| 27 | 19506-MKF-D40 | HOSE, THERMOSTAT COVER | 1 шт. | — | |
|
| 28 | 19508-MKF-D40 | HOSE B, L. RADIATOR | 1 шт. | — | |
|
| 29 | 19509-MKF-D40 | PIPE, WATER | 1 шт. | — | |
|
| 30 | 19511-MFL-000 | TUBE, WATER | 1 шт. | — | |
|
| 31 | 19511-MKF-D41 | CLAMP, HOSE (D19) | 2 шт. | — | |
|
| 32 | 19514-MFJ-D00 | JOINT, HOSE (THREE-WAY) | 1 шт. | — | |
|
| 33 | 19514-MKF-D41 | CLAMP, HOSE (D29.8) | 8 шт. | — | |
|
| 34 | 90116-MCS-G00 | RIVET, PUSH | 1 шт. | — | |
|
| 35 | 90120-GHB-601 | BOLT-WASHER (6X12) | 6 шт. | — | |
|
| 36 | 90315-MFL-003 | NUT, FLANGE (3MM) | 1 шт. | — | |
|
| 37 | 90315-MK3-003 | NUT, SERRATE (5MM) | 4 шт. | — | |
|
| 38 | 90683-GR1-003 | CLIP, BODY COVER | 2 шт. | — | |
|
| 39 | 91549-MW0-790ZA | CLIP, PANEL FIXING *NH1* (BLACK) | 2 шт. | — | |
|
| 40 | 93891-04006-07 | SCREW-WASHER (4X6) | 3 шт. | — | |
|
| 41 | 95002-02100 | CLIP, TUBE (B10) | 2 шт. | — | |
|
| 42 | 95002-41250-08 | CLAMP, TUBE (D12.5) | 2 шт. | — | |
|
| 43 | 95002-50000 | CLIP, TUBE (C9) | 1 шт. | — | |
|
| 44 | 95005-50003-30M | BULK HOSE, VACUUM (5X3000) (5X180) | 1 шт. | — | |
|
| 45 | 95005-55003-20M | BULK HOSE, VACUUM (5.5X3000) (95005-55001-20M(95005-55001-2 | 1 шт. | — | |
|
| 46 | 96001-06025-00 | BOLT, FLANGE (6X25) | 2 шт. | — | |
|
| 47 | 96300-06016-00 | BOLT, FLANGE (6X16) | 1 шт. | — | |
|
