| 1 | 50010-MKN-D10ZA | FRAME SET *NH303M* (MAT AXIS GRAY METALLIC) Use up to Frame SN L5100064. | 1 шт. | — | |
|
| 2 | 50010-MKN-D11ZA | FRAME SET *NH303M* (MAT AXIS GRAY METALLIC) Use from Frame SN L5100065. | 1 шт. | — | — |
|
| 3 | 50211-MKN-D50ZA | BRACKET B, R. ENGINE HANGER *NH303M* (MAT AXIS GRAY METALLIC) | 1 шт. | — | |
|
| 4 | 50212-MKN-D50ZA | BRACKET B, L. ENGINE HANGER *NH303M* (MAT AXIS GRAY METALLIC) | 1 шт. | — | |
|
| 5 | 50351-MKN-D50 | COLLAR A, L. ENGINE HANGER | 1 шт. | — | |
|
| 6 | 50352-MKN-D50 | COLLAR C, ENGINE HANGER | 1 шт. | — | |
|
| 7 | 52161-MKN-D50 | CAP, SWINGARM PIVOT | 2 шт. | — | |
|
| 8 | 64341-MKN-D50 | COVER, R. FRAME | 1 шт. | — | |
|
| 9 | 64351-MKN-D50 | COVER, L. FRAME | 1 шт. | — | |
|
| 10 | 90105-MJE-D00 | BOLT, SOCKET (10X30) | 2 шт. | — | |
|
| 11 | 90116-KW3-000 | BOLT, FLANGE (10X138) | 1 шт. | — | |
|
| 12 | 90127-KYJ-900 | BOLT, SOCKET (8X22) | 4 шт. | — | |
|
| 13 | 90167-GHB-710 | BOLT, FLANGE (12X40) | 1 шт. | — | |
|
| 14 | 90167-GHB-760 | BOLT, FLANGE (12X65) | 1 шт. | — | |
|
| 15 | 94050-10000 | NUT, FLANGE (10MM) | 1 шт. | — | |
|
| 16 | 94050-12000 | NUT, FLANGE (12MM) | 1 шт. | — | |
|
| 17 | 95801-12160-08 | BOLT, FLANGE (12X160) | 1 шт. | — | |
|
