| 1 | 33740-MFR-B11 | REFLECTOR, FR. REFLEX | 2 шт. | — | |
|
| 2 | 51400-MFR-681 | FORK ASSY., R. FR. (SHOWA) | 1 шт. | — | |
|
| 3 | 51401-MFR-671 | SPRING, FR. FORK | 2 шт. | — | |
|
| 4 | 51402-MFR-671 | COLLAR, SPRING | 1 шт. | — | |
|
| 5 | 51402-ML7-921 | COLLAR, SPRING (R. SIDE) | 1 шт. | — | |
|
| 6 | 51404-MR7-003 | SEAT, SPRING | 1 шт. | — | |
|
| 7 | 51405-KA4-711 | SEAT, SPRING | 2 шт. | — | |
|
| 8 | 51405-MCZ-D11 | COLLAR, SPRING | 1 шт. | — | |
|
| 9 | 51410-MFR-671 | PIPE, FR. FORK | 2 шт. | — | |
|
| 10 | 51412-KZ3-003 | RING, BACK-UP | 2 шт. | — | |
|
| 11 | 51414-MFR-671 | BUSH, GUIDE | 2 шт. | — | |
|
| 12 | 51415-MFR-671 | BUSH, SLIDER | 2 шт. | — | |
|
| 13 | 51416-MFR-671 | SPRING, FR. REBOUND | 1 шт. | — | |
|
| 14 | 51420-MFR-681 | CASE, R. (LOWER) | 1 шт. | — | |
|
| 15 | 51430-MFR-671 | DAMPER, FR. | 1 шт. | — | |
|
| 16 | 51432-MS2-003 | PIECE, OIL LOCK (SHOWA) | 1 шт. | — | |
|
| 17 | 51432-MV9-003 | PIECE, OIL LOCK (SHOWA) | 1 шт. | — | |
|
| 18 | 51437-MCA-003 | RING, PISTON | 1 шт. | — | |
|
| 19 | 51447-KZ3-003 | RING, OIL SEAL STOPPER | 2 шт. | — | |
|
| 20 | 51451-MAJ-G41 | NUT, HEX. (10MM) | 1 шт. | — | |
|
| 21 | 51454-MBR-003 | BOLT, FR. FORK | 1 шт. | — | |
|
| 22 | 51454-MCA-003 | BOLT, FR. FORK | 1 шт. | — | |
|
| 23 | 51490-MFR-671 | SEAL SET, FR. FORK | 2 шт. | — | |
|
| 24 | 51500-MFR-681 | FORK ASSY., L. FR. (SHOWA) | 1 шт. | — | |
|
| 25 | 51520-MFR-681 | CASE, L. (LOWER) | 1 шт. | — | |
|
| 26 | 51540-MFR-671 | PIPE, SEAT | 1 шт. | — | |
|
| 27 | 90116-383-721 | BOLT, SOCKET (8X27) BOLT, SOCKET (8MM) (SHOWA) | 2 шт. | — | |
|
| 28 | 90122-MCH-A00 | BOLT, SOCKET (8X32) | 4 шт. | — | |
|
| 29 | 90544-283-000 | WASHER, SPECIAL (8MM) (SHOWA) | 2 шт. | — | |
|
| 30 | 91254-MCH-C11 | DUST SEAL | 2 шт. | — | |
|
| 31 | 91356-MW0-003 | O-RING (37.2X2.4) (SHOWA) | 2 шт. | — | |
|
