| 1 | 06410-MAZ-000 | DAMPER SET, WHEEL | 1 шт. | — | |
|
| 2 | 42301-MFR-670 | AXLE, RR. WHEEL | 1 шт. | — | |
|
| 3 | 42312-MFR-670 | COLLAR, RR. WHEEL | 1 шт. | — | |
|
| 4 | 42516-MFR-A00 | COVER, PULSER RING | 1 шт. | — | |
|
| 5 | 42614-MCH-000 | FLANGE B, FINAL DRIVEN | 1 шт. | — | |
|
| 6 | 42620-MFR-670 | COLLAR, RR. AXLE DISTANCE | 1 шт. | — | |
|
| 7 | 42624-MFR-670 | COLLAR A, RR. AXLE DISTANCE | 1 шт. | — | |
|
| 8 | 42630-MCH-000 | FLANGE SET, FINAL DRIVEN | 1 шт. | — | |
|
| 9 | 42650-MFR-A21 | WHEEL SUB-ASSY., RR. | 1 шт. | — | |
|
| 10 | 42704-MER-D00 | WEIGHT, BALANCE (10G) | 1 шт. | — | |
|
| 11 | 42705-MER-D00 | WEIGHT, BALANCE (20G) | 1 шт. | — | |
|
| 12 | 42706-MER-D00 | WEIGHT, BALANCE (30G) | 1 шт. | — | |
|
| 13 | 42711-MFR-674 | TIRE, RR. (200/50R18 M/C 76H) (DUNLOP) | 1 шт. | — | |
|
| 14 | 42711-MFR-764 | TIRE, RR. (200/50R18 M/C 76H) (METZELER) | 0 шт. | — | |
|
| 15 | 42753-MCF-008 | VALVE, RIM (PIRELLI) | 1 шт. | — | |
|
| 16 | 42753-ML7-004 | VALVE, RIM (DUNLOP) | 1 шт. | — | |
|
| 17 | 43251-MFR-A01 | DISK, RR. BRAKE | 1 шт. | — | |
|
| 18 | 44515-MFR-A00 | RING, FR. PULSER (RR.) | 1 шт. | — | |
|
| 19 | 90105-KL8-741 | BOLT, FR. DISK (8X24) (SAGA) | 6 шт. | — | |
|
| 20 | 90131-KFK-630 | BOLT, TORX (5X10) | 3 шт. | — | |
|
| 21 | 90305-MCF-D01 | NUT, U (22MM) | 1 шт. | — | |
|
| 22 | 90306-KF0-003 | NUT, FLANGE (12MM) (FUSE RASHI) | 5 шт. | — | |
|
| 23 | 90401-MAZ-000 | WASHER (22X38X2.5) | 1 шт. | — | |
|
| 24 | 90651-MCH-000 | CIRCLIP (INNER) (188) | 1 шт. | — | |
|
| 25 | 91052-KZ4-J21 | BEARING, RADIAL BALL (6905RS) | 2 шт. | — | |
|
| 26 | 91053-MAZ-003 | BEARING, RADIAL BALL (6205X2) | 1 шт. | — | |
|
| 27 | 91053-MFR-671 | BEARING, RADIAL BALL (60/28) | 2 шт. | — | |
|
| 28 | 91254-MEE-003 | DUST SEAL (35X52X7.5) | 1 шт. | — | |
|
| 29 | 91302-MA6-003 | O-RING (61X2) | 1 шт. | — | |
|
| 30 | 91358-MG9-003 | O-RING (50.5X3.5) (ARAI) | 1 шт. | — | |
|
| 31 | 91358-MG9-004 | O-RING (50.5X3.5) (NOK) | 1 шт. | — | |
|
| 32 | 92900-12032-0E | BOLT 2, STUD (12X32) | 5 шт. | — | |
|
