| 1 | 06910-MFR-670 | BEARING SET, NEEDLE | 1 шт. | — | |
|
| 2 | 12361-035-000 | CAP, TAPPET ADJUSTING HOLE | 1 шт. | — | |
|
| 3 | 12361-300-000 | CAP, VALVE ADJ. | 1 шт. | — | |
|
| 4 | 12361-371-980 | CAP, VALVE ADJ. | 1 шт. | — | |
|
| 5 | 12392-MJ0-000 | PLUG, HEX. (6MM) | 1 шт. | — | |
|
| 6 | 41300-MFR-680 | GEAR ASSY., FINAL | 1 шт. | — | |
|
| 7 | 41302-MFR-670 | COLLAR, GEAR CASE SIDE | 1 шт. | — | |
|
| 8 | 41305-MB4-770 | RING, STOPPER | 1 шт. | — | |
|
| 9 | 41310-MFR-670 | GEAR SET, FINAL | 1 шт. | — | |
|
| 10 | 41311-MFR-680 | CASE SUB-ASSY., FINAL GEAR | 1 шт. | — | |
|
| 11 | 41320-MFR-670 | COVER SUB-ASSY., FINAL GEAR | 1 шт. | — | |
|
| 12 | 41324-MFR-680 | PLATE, DUST GUARD | 1 шт. | — | |
|
| 13 | 41331-MN5-000 | RETAINER, BEARING | 1 шт. | — | |
|
| 14 | 41332-415-000 | LOCK A, BEARING ADJUSTING (SINGLE TAB) | 1 шт. | — | |
|
| 15 | 41333-415-000 | LOCK B, BEARING ADJUSTING (DOUBLE TABS) | 1 шт. | — | |
|
| 16 | 41391-MFR-670 | TUBE, FINAL GEAR BREATHER | 1 шт. | — | |
|
| 17 | 41410-ME9-770 | JOINT, PINION | 1 шт. | — | |
|
| 18 | 41436-MB0-310 | PIN, RING GEAR STOPPER | 1 шт. | — | |
|
| 19 | 41437-MB0-310 | SHIM A, STOPPER PIN (0.10) | 1 шт. | — | |
|
| 20 | 41438-MB0-310 | SHIM B, STOPPER PIN (0.15) | 1 шт. | — | |
|
| 21 | 41450-MG9-000 | SHIM A, PINION GEAR (1.32) | 1 шт. | — | |
|
| 22 | 41451-MG9-000 | SHIM B, PINION GEAR (1.38) | 1 шт. | — | |
|
| 23 | 41452-MG9-000 | SHIM C, PINION GEAR (1.44) | 1 шт. | — | |
|
| 24 | 41453-MG9-000 | SHIM D, PINION GEAR (1.50) | 1 шт. | — | |
|
| 25 | 41454-MG9-000 | SHIM E, PINION GEAR (1.56) | 1 шт. | — | |
|
| 26 | 41455-MG9-000 | SHIM F, PINION GEAR (1.62) | 1 шт. | — | |
|
| 27 | 41456-MG9-000 | SHIM G, PINION GEAR (1.68) | 1 шт. | — | |
|
| 28 | 41510-MFR-670 | WASHER, SPECIAL (46X54) | 1 шт. | — | |
|
| 29 | 41530-MG9-000 | SPACER A, RING GEAR (1.82) | 1 шт. | — | |
|
| 30 | 41531-MG9-000 | SPACER B, RING GEAR (1.88) | 1 шт. | — | |
|
| 31 | 41532-MG9-000 | SPACER C, RING GEAR (1.94) | 1 шт. | — | |
|
| 32 | 41533-MG9-000 | SPACER D, RING GEAR (2.00) | 1 шт. | — | |
|
| 33 | 41534-MG9-000 | SPACER E, RING GEAR (2.06) | 1 шт. | — | |
|
| 34 | 41535-MG9-000 | SPACER F, RING GEAR (2.12) | 1 шт. | — | |
|
| 35 | 41536-MG9-000 | SPACER G, RING GEAR (2.18) | 1 шт. | — | |
|
| 36 | 41537-MG9-000 | SPACER H, RING GEAR (2.24) | 1 шт. | — | |
|
| 37 | 41538-MG9-000 | SPACER I, RING GEAR (2.30) | 1 шт. | — | |
|
| 38 | 42625-MFR-670 | COLLAR B, RR. AXLE DISTANCE | 1 шт. | — | |
|
| 39 | 44313-HP2-670 | WASHER, FR. HUB | 1 шт. | — | |
|
| 40 | 90013-883-000 | BOLT, FLANGE (6X12) (CT200) | 1 шт. | — | |
|
| 41 | 90107-MFR-670 | BOLT, SOCKET (8X16) | 1 шт. | — | |
|
| 42 | 90109-ME5-770 | BOLT, SOCKET (8X11) | 1 шт. | — | |
|
| 43 | 90133-MCA-000 | BOLT, FLANGE (8X30) | 6 шт. | — | |
|
| 44 | 90134-MCA-000 | BOLT, FLANGE (10X38) | 2 шт. | — | |
|
| 45 | 90138-MFR-670 | BOLT, PINION JOINT | 1 шт. | — | |
|
| 46 | 90471-580-000 | WASHER (8MM) | 1 шт. | — | |
|
| 47 | 90651-MFR-670 | CIRCLIP (INNER) (52MM) | 1 шт. | — | |
|
| 48 | 90652-MFR-670 | CIRCLIP (INNER) (45MM) | 1 шт. | — | |
|
| 49 | 91051-MFR-671 | BEARING, RADIAL BALL (30X52X9) | 1 шт. | — | |
|
| 50 | 91052-MFR-671 | BEARING, RADIAL BALL (45X68X19) | 1 шт. | — | |
|
| 51 | 91053-MCH-003 | BEARING, RADIAL BALL (65X100X14) | 1 шт. | — | |
|
| 52 | 91061-MT3-003 | BEARING, RADIAL BALL (QJ3/28V1) | 1 шт. | — | |
|
| 53 | 91071-MFR-671 | BEARING, NEEDLE (35X45X24) | 1 шт. | — | |
|
| 54 | 91251-MFR-671 | DUST SEAL (38X52X5) | 1 шт. | — | |
|
| 55 | 91252-MFR-671 | OIL SEAL (45X55X6) | 1 шт. | — | |
|
| 56 | 91262-MCH-003 | OIL SEAL (39X56X7) | 1 шт. | — | |
|
| 57 | 91265-MCH-003 | OIL SEAL (65X85X7) | 1 шт. | — | |
|
| 58 | 91302-001-020 | O-RING (30.8MM) (Honda Code 0001065) | 1 шт. | — | |
|
| 59 | 91359-MG9-003 | O-RING (64.5X3.5) (ARAI) | 1 шт. | — | |
|
| 60 | 92101-06012-0A | BOLT, HEX. (6X12) BOLT, FLANGE (6X12) | 1 шт. | — | |
|
| 61 | 95002-02079 | CLIP, TUBE (B17) | 1 шт. | — | |
|
