| 1 | 50603-KZZ-900 | PIN, STEP JOINT | 2 шт. | — | |
|
| 2 | 50616-KZZ-305 | STEP, R. (COO) | 1 шт. | — | |
|
| 3 | 50616-KZZ-900 | STEP, R. | 1 шт. | — | |
|
| 4 | 50617-KZZ-900 | SPRING, R. STEP RETURN | 1 шт. | — | |
|
| 5 | 50618-KZZ-900 | SPRING, L. STEP RETURN | 1 шт. | — | |
|
| 6 | 50639-KZZ-900 | PIN, STEP BAR | 2 шт. | — | |
|
| 7 | 50642-KZZ-305 | STEP, L. (COO) | 1 шт. | — | |
|
| 8 | 50642-KZZ-900 | STEP, L. | 1 шт. | — | |
|
| 9 | 50711-KZZ-305 | STEP, PILLION (COO) | 2 шт. | — | |
|
| 10 | 50711-KZZ-900 | STEP, PILLION | 2 шт. | — | |
|
| 11 | 50713-KZZ-900 | GUIDE, PILLION STEP | 2 шт. | — | |
|
| 12 | 90020-KZZ-900 | SCREW, PAN (4X10) | 2 шт. | — | |
|
| 13 | 94101-08000 | WASHER, PLAIN (8MM) | 2 шт. | — | |
|
| 14 | 94102-10000 | WASHER, PLAIN (10MM) | 2 шт. | — | |
|
| 15 | 94201-20150 | PIN, COTTER (2.0X15) | 2 шт. | — | |
|
| 16 | 94201-20180 | PIN, COTTER (2.0X18) PIN, COTTER (2.0X20) | 2 шт. | — | |
|
| 17 | 94201-20200 | PIN, COTTER (2.0X20) PIN, COTTER (2.0X22) | 2 шт. | — | |
|
| 18 | 94201-20220 | PIN, COTTER (2.0X22) PIN, COTTER (2.0X25) | 2 шт. | — | |
|
| 19 | 94201-20250 | PIN, COTTER (2.0X25) PIN, COTTER (2X28) | 2 шт. | — | |
|
| 20 | 94201-20280 | PIN, SPLIT (2.0X28) PIN, COTTER (2.0X32) | 2 шт. | — | |
|
| 21 | 94201-20320 | PIN, COTTER (2.0X32) PIN, COTTER (2.0X35) | 2 шт. | — | |
|
| 22 | 94201-20350 | PIN, COTTER (2.0X35) PIN, COTTER (2.0X22) | 2 шт. | — | |
|
| 23 | 94201-29220 | PIN, COTTER (2.0X22) | 2 шт. | — | |
|
