| 1 | 30510-KZZ-901 | COIL, IGNITION | 1 шт. | — | |
|
| 2 | 30520-GFM-900 | SPACER, IGNITION COIL | 2 шт. | — | |
|
| 3 | 30700-KZZ-901 | CAP ASSY., NOISE SUPPRESSOR | 1 шт. | — | |
|
| 4 | 31600-KZZ-J01 | RECTIFIER ASSY., REGULATOR | 1 шт. | — | |
|
| 5 | 31700-MM8-610 | RECTIFIER, SILICON | 1 шт. | — | |
|
| 6 | 31730-MAS-601 | DIODE ASSY., THREE WAY (SUMITOMO) | 1 шт. | — | |
|
| 7 | 32100-KZZ-J10 | WIRE HARNESS | 1 шт. | — | |
|
| 8 | 32103-KZZ-J00 | SUB-HARNESS, FR. | 1 шт. | — | |
|
| 9 | 32161-404-000 | BAND B1, CABLE BAND A1, CABLE | 1 шт. | — | |
|
| 10 | 32606-GEV-761 | CAP, DUMMY (4P) (RED) (Honda Code 7679160) | 1 шт. | — | |
|
| 11 | 35160-KVS-751 | SENSOR ASSY., BANK ANGLE (M6) | 1 шт. | — | |
|
| 12 | 35161-KZZ-900 | STAY, BANK ANGLE SENSOR | 1 шт. | — | |
|
| 13 | 37244-MM4-000 | RUBBER, SPEEDOMETER MOUNTING | 2 шт. | — | |
|
| 14 | 38110-KYJ-901 | HORN (HIGH) | 1 шт. | — | |
|
| 15 | 38301-KYJ-641 | RELAY, TURN SIGNAL (MITSUBA) | 1 шт. | — | |
|
| 16 | 38501-KWN-901 | RELAY, POWER (MICRO ISO 4P) (OMRON) | 1 шт. | — | |
|
| 17 | 38506-KZZ-900 | COVER, RELAY (2P) | 1 шт. | — | |
|
| 18 | 38770-KZZ-J11 | PGM-FI UNIT | 1 шт. | — | |
|
| 19 | 38771-KTY-D30 | CUSHION, PGM-FI UNIT | 1 шт. | — | |
|
| 20 | 77302-473-000 | COLLAR, PILLION SEAT | 2 шт. | — | |
|
| 21 | 90650-KW3-000 | BAND, WIRE | 2 шт. | — | |
|
| 22 | 90651-KV6-003 | BAND, WIRE (165MM) (BLACK) | 2 шт. | — | |
|
| 23 | 90651-MA6-720 | BAND, WIRE HARNESS | 1 шт. | — | |
|
| 24 | 90679-SG9-E01 | BAND, SUCTION HOSE (BLACK) (Honda Code 3522752) | 1 шт. | — | |
|
| 25 | 91533-S5A-003 | CLIP, CONNECTOR (NATURAL) | 1 шт. | — | |
|
| 26 | 91534-SWA-003 | CLIP, CONNECTOR (DARK GRAY) | 1 шт. | — | |
|
| 27 | 91565-S0X-003 | CLIP, CONNECTOR (DARK GREEN) | 1 шт. | — | |
|
| 28 | 92101-06020-4J | BOLT, HEX. (6X20) | 2 шт. | — | |
|
| 29 | 94050-06000 | NUT, FLANGE (6MM) | 2 шт. | — | |
|
| 30 | 94102-08000 | WASHER, PLAIN (8MM) | 1 шт. | — | |
|
| 31 | 95701-06012-00 | BOLT, FLANGE (6X12) BOLT, SPECIAL (6X12) | 1 шт. | — | |
|
| 32 | 95701-06022-00 | BOLT, FLANGE (6X22) | 2 шт. | — | |
|
| 33 | 95701-06030-00 | BOLT, FLANGE (6X30) | 2 шт. | — | |
|
| 34 | 95701-08014-00 | BOLT, FLANGE (8X14) | 1 шт. | — | |
|
| 35 | 98200-41000 | FUSE, MINI (10A) | 6 шт. | — | |
|
| 36 | 98200-42000 | FUSE, MINI (20A) | 2 шт. | — | |
|
| 37 | 32401-KZZ-900 | CABLE, STARTER MAGNETIC BATTERY | 1 шт. | — | |
|
| 38 | 32406-MFF-D00 | COVER, STARTER MAGNETIC TERMINAL | 1 шт. | — | |
|
| 39 | 32414-GAG-000 | COVER, BATTERY TERMINAL | 1 шт. | — | |
|
| 40 | 38306-KK4-000 | SUSPENSION, TURN SIGNAL RELAY (MITSUBA) | 1 шт. | — | |
|
