| 1 | 06410-GCR-000 | DAMPER SET, WHEEL | 1 шт. | — | |
|
| 2 | 06420-K2E-T00 | SPOKE SET (B9X161.5) (OUTSIDE) | 18 шт. | — | |
|
| 3 | 06421-K2E-T00 | SPOKE SET (B9X161.5) (INSIDE) | 18 шт. | — | |
|
| 4 | 41200-K2E-T00 | SPROCKET, FINAL DRIVEN (39T) | 1 шт. | — | |
|
| 5 | 42303-KBA-900 | SLEEVE, RR. WHEEL | 1 шт. | — | |
|
| 6 | 42304-K2E-T00 | COLLAR, RR. WHEEL SIDE | 1 шт. | — | |
|
| 7 | 42313-KTM-750 | COLLAR, R. RR. WHEEL SIDE | 1 шт. | — | |
|
| 8 | 42615-K2E-T00ZA | FLANGE SUB-ASSY., FINAL DRIVEN *NH303M* (MAT AXIS GRAY METALLIC) | 1 шт. | — | |
|
| 9 | 42620-KW7-880 | COLLAR, RR. AXLE DISTANCE | 1 шт. | — | |
|
| 10 | 42635-K2E-T00ZA | HUB SUB-ASSY., RR. *NH303M* (MAT AXIS GRAY METALLIC) | 1 шт. | — | |
|
| 11 | 42650-K2E-T01ZA | WHEEL SUB-ASSY., RR. *NH303M* (MAT AXIS GRAY METALLIC) | 1 шт. | — | |
|
| 12 | 42653-001-004 | O-RING (40.5X3) (NIPPON DUST KEEPER) | 1 шт. | — | |
|
| 13 | 42701-K2E-T01 | RIM, RR. WHEEL (17X1.60) | 1 шт. | — | |
|
| 14 | 42711-K2E-T01 | TIRE, RR. (80/90-17 M/C 50P) (IRC) | 1 шт. | — | |
|
| 15 | 42712-K2E-T01 | TUBE, TIRE (IRC) | 1 шт. | — | |
|
| 16 | 42712-K2E-T02 | TUBE, TIRE | 1 шт. | — | |
|
| 17 | 42713-102-005 | FLAP, TIRE (17) (INOUE) FLAP, TIRE (17) (NITTO) | 1 шт. | — | |
|
| 18 | 43351-KTM-N31 | DISK, RR. BRAKE (YUTAKA) | 0 шт. | — | |
|
| 19 | 43351-KTM-N32 | DISK, RR. BRAKE (SUNSTAR) | 1 шт. | — | |
|
| 20 | 44301-K01-900 | AXLE, FR. WHEEL (FOR RR.) | 1 шт. | — | |
|
| 21 | 90105-KGH-900 | BOLT, BRAKE DISK (8X24) | 4 шт. | — | |
|
| 22 | 90128-KFM-900 | BOLT, STUD (8X19.5) | 4 шт. | — | |
|
| 23 | 90306-K0G-901 | NUT, U (12MM) | 1 шт. | — | |
|
| 24 | 90309-KPH-971 | NUT, U (8MM) (FUJI SEIMITSU) | 4 шт. | — | |
|
| 25 | 90501-K0G-900 | WASHER, RR. AXLE | 2 шт. | — | |
|
| 26 | 90559-K0G-900 | PLATE, SWINGARM SIDE | 2 шт. | — | |
|
| 27 | 90753-051-003 | OIL SEAL (26X37X6) (ARAI) | 1 шт. | — | |
|
| 28 | 90753-051-005 | OIL SEAL (26X37X6) (NOK) | 1 шт. | — | |
|
| 29 | 91051-K35-V03 | BEARING, RADIAL BALL (6203UU) (FUJIKOSHI) | 1 шт. | — | |
|
| 30 | 91051-K35-V04 | BRG,BALL RADIAL 6 | 1 шт. | — | |
|
| 31 | 91053-K03-H01 | BEARING, RADIAL BALL (6301U L) (NTN) | 2 шт. | — | |
|
| 32 | 91053-K03-H02 | BEARING, RADIAL BALL (6301U L) (FAG) | 2 шт. | — | |
|
| 33 | 91053-K03-N41 | BEARING, RADIAL BALL (6301U L) (SKF) | 2 шт. | — | |
|
| 34 | 91055-KVS-F01 | BEARING, RADIAL BALL (6301U L) (FUJIKOSHI) | 2 шт. | — | |
|
| 35 | 91055-KVS-F02 | BEARING, RADIAL BALL (6301U L) (NSK) | 2 шт. | — | |
|
| 36 | 91251-KGH-902 | DUST SEAL (27X40X4.5) (NOK) | 1 шт. | — | |
|
