| 1 | 18450-24F03 | VALVE ASSY, 2ND AIR | 1 шт. | — | |
|
| 2 | 07130-06353 | BOLT | 2 шт. | — | |
|
| 3 | 18630-24F10 | SPACER, 2ND AIR VALVE SUPPORT | 0 шт. | — | |
|
| 4 | 09320-10015 | CUSHION, 2ND AIR VALVE SUPPORT | 2 шт. | — | |
|
| 5 | 09160-06088 | WASHER, 2ND AIR VALVE SUPPORT | 2 шт. | — | |
|
| 6 | 08316-10063 | NUT, 2ND AIR VALVE SUPPORT | 2 шт. | — | |
|
| 7 | 18610-24F01 | BRACKET, 2ND AIR VALVE | 0 шт. | — | |
|
| 8 | 09103-06285 | BOLT | 3 шт. | — | |
|
| 9 | 18620-24F00 | BRACKET, 2ND AIR VALVE BRACKET | 0 шт. | — | |
|
| 10 | 09355-35755-00B | HOSE, VACUUM (3.5X7.5X2000) L:2000!650 | 1 шт. | — | |
|
| 11 | 18711-24F00 | HOSE, 2ND AIR CLEANER | 1 шт. | — | |
|
| 12 | 09401-15101 | CLIP | 2 шт. | — | |
|
| 13 | 18461-24F00 | HOSE, 2ND AIR VALVE FR | 0 шт. | — | |
|
| 14 | 18491-24F00 | HOSE, 2ND AIR VALVE RH | 0 шт. | — | |
|
| 15 | 09401-13409 | CLIP | 8 шт. | — | |
|
| 16 | 18410-24F00 | PIPE, 2ND AIR NO.1 | 0 шт. | — | |
|
| 17 | 18420-24F00 | PIPE, 2ND AIR NO.2 | 0 шт. | — | |
|
| 18 | 18430-24F00 | PIPE, 2ND AIR NO.3 | 0 шт. | — | |
|
| 19 | 18440-24F00 | PIPE, 2ND AIR NO.4 | 0 шт. | — | |
|
| 20 | 18441-45C01 | GASKET 2ND AIR PIPE | 4 шт. | — | |
|
| 21 | 01421-06163 | BOLT, STUD | 8 шт. | — | |
|
| 22 | 08316-10063 | NUT | 8 шт. | — | |
|
| 23 | 09404-06429 | CLAMP, 2ND AIR VACUUM HOSE | 2 шт. | — | |
|
