| 1 | 43510-24F00 | BRACKET, FRONT FOOTREST RH | 1 шт. | — | |
|
| 2 | 43521-24F00 | BRACKET, FRONT FOOTREST LH | 0 шт. | — | |
|
| 3 | 09106-08147 | BOLT, BRACKET | 6 шт. | — | |
|
| 4 | 09161-13004 | WASHER, OUTER | 6 шт. | — | |
|
| 5 | 09161-17002 | WASHER, INNER | 6 шт. | — | |
|
| 6 | 09319-08045 | BUSH | 6 шт. | — | |
|
| 7 | 43531-24F00 | BAR, FRONT FOOTREST RH | 1 шт. | — | |
|
| 8 | 43541-24F00 | BAR, FRONT FOOTREST LH | 1 шт. | — | |
|
| 9 | 43550-24F00 | RUBBER | 2 шт. | — | |
|
| 10 | 09208-08016 | PIN | 2 шт. | — | |
|
| 11 | 08332-11063 | E RING | 2 шт. | — | |
|
| 12 | 09448-18022 | SPRING | 2 шт. | — | |
|
| 13 | 43536-31E20 | BALANCER | 2 шт. | — | |
|
| 14 | 02142-05353 | SCREW, INNER | 2 шт. | — | |
|
| 15 | 02142-05253 | SCREW, OUTER | 2 шт. | — | |
|
| 16 | 43576-48B02 | BOLT, BANK SENSOR | 1 шт. | — | |
|
| 17 | 43576-48B20 | BOLT, BANK SENSOR LH | 1 шт. | — | |
|
| 18 | 43600-24F00 | FOOTREST ASSY, PILLION RH | 0 шт. | — | |
|
| 19 | 43700-24F00 | FOOTREST ASSY, PILLION LH Includes Item(s) 20 - 27 | 1 шт. | — | |
|
| 20 | 43610-33E11 | BAR, PILLION RH | 1 шт. | — | |
|
| 21 | 43620-33E11 | BAR, PILLION LH | 1 шт. | — | |
|
| 22 | 09208-06007 | PIN | 2 шт. | — | |
|
| 23 | 09440-05005 | SPRING | 2 шт. | — | |
|
| 24 | 06111-07004 | BALL | 2 шт. | — | |
|
| 25 | 43816-33E21 | PLATE, RH | 1 шт. | — | |
|
| 26 | 43826-33E22 | PLATE, LH | 1 шт. | — | |
|
| 27 | 08332-11043 | E RING | 2 шт. | — | |
|
| 28 | 09106-08121 | BOLT, BRACKET | 4 шт. | — | |
|
