| 1 | 49100-24F20-YKZ | TANK ASSY, FUEL (BLUE) E3,E28 FOR CZV | 1 шт. | — | |
|
| 2 | 49100-24F20-YHL | TANK ASSY, FUEL (RED) E3,E28 FOR CZW | 0 шт. | — | |
|
| 3 | 49100-24F20-YAY | TANK ASSY, FUEL (BLACK) E3,E28 FOR CZY | 1 шт. | — | |
|
| 4 | 49100-24F40-YKZ | TANK ASSY, FUEL (BLUE) E33 FOR CZV | 0 шт. | — | |
|
| 5 | 49100-24F40-YHL | TANK ASSY, FUEL (RED) E33 FOR CZW | 0 шт. | — | |
|
| 6 | 49100-24F40-YAY | TANK ASSY, FUEL (BLACK) E33 FOR CZY; Includes Item(s) 2 - 3 | 0 шт. | — | |
|
| 7 | 68110-24F30-DAJ | TAPE SET, UPPER FOR YKZ | 0 шт. | — | |
|
| 8 | 68110-24F30-DAK | TAPE SET, UPPER FOR YHL | 0 шт. | — | |
|
| 9 | 68110-24F30-DAL | TAPE SET, UPPER FOR YAY | 0 шт. | — | |
|
| 10 | 68110-24F40-CZV | TAPE SET, LOWER FOR YKZ | 0 шт. | — | |
|
| 11 | 68110-24F40-CZW | TAPE SET, LOWER FOR YHL | 0 шт. | — | |
|
| 12 | 68110-24F40-CZY | TAPE SET, LOWER FOR YAY | 0 шт. | — | |
|
| 13 | 68111-18G20 | EMBLEM | 2 шт. | — | |
|
| 14 | 44201-33810 | CAP SET, FUEL TANK E3,E28 | 1 шт. | — | |
|
| 15 | 44200-33890 | CAP SET, FUEL TANK E33 | 1 шт. | — | |
|
| 16 | 09106-05017 | BOLT | 4 шт. | — | |
|
| 17 | 44191-24F10 | SHIELD, HEAT | 0 шт. | — | |
|
| 18 | 09139-06029 | BOLT, FRONT | 2 шт. | — | |
|
| 19 | 09160-06036 | WASHER | 2 шт. | — | |
|
| 20 | 09320-09009 | CUSHION | 2 шт. | — | |
|
| 21 | 09169-06062 | WASHER (6.3X17X1.6) | 2 шт. | — | |
|
| 22 | 44533-24F00 | COVER, SIDE RH | 1 шт. | — | |
|
| 23 | 44543-24F00 | COVER, SIDE LH | 1 шт. | — | |
|
| 24 | 44540-24F10 | PLATE, SIDE | 2 шт. | — | |
|
| 25 | 02142-06103 | SCREW | 2 шт. | — | |
|
| 26 | 44560-24F01 | BRACKET, TANK | 1 шт. | — | |
|
| 27 | 09116-06152 | BOLT | 4 шт. | — | |
|
| 28 | 09320-08001 | CUSHION | 4 шт. | — | |
|
| 29 | 09169-06062 | WASHER (6.3X17X1.6) | 4 шт. | — | |
|
| 30 | 44541-24F00 | CUSHION, JOINT | 2 шт. | — | |
|
| 31 | 44561-33E10 | SPACER | 1 шт. | — | |
|
| 32 | 01550-08953 | BOLT | 1 шт. | — | |
|
| 33 | 44574-33E01 | STAY | 1 шт. | — | |
|
| 34 | 09403-05310 | CLIP | 1 шт. | — | |
|
| 35 | 44550-24F00 | BRACKET, REAR | 1 шт. | — | |
|
| 36 | 01550-08123 | BOLT, LOWER | 2 шт. | — | |
|
| 37 | 44423-24F00 | HOSE, BREATHER | 1 шт. | — | |
|
| 38 | 09352-70113-600 | HOSE, DRAIN L:600!500 | 1 шт. | — | |
|
| 39 | 09404-06433 | CLAMP, DRAIN HOSE | 1 шт. | — | — |
|
| 40 | 44534-24F00 | CUSHION (20X20X1) | 2 шт. | — | |
|
| 41 | 44535-24F00 | CUSHION, REAR | 2 шт. | — | |
|
| 42 | 44271-24F00 | SHEET, HEAT SHIELD RUBBER | 1 шт. | — | |
|
| 43 | 09407-18402 | CLAMP | 2 шт. | — | |
|
| 44 | 09409-06322-5PK | CLIP (5.9X20.5,BLACK) | 1 шт. | — | |
|
