| 1 | 16600-24F10 | COOLER ASSY, OIL | 0 шт. | — | |
|
| 2 | 09116-06167 | BOLT (6X20) | 3 шт. | — | |
|
| 3 | 09180-06310 | SPACER | 3 шт. | — | |
|
| 4 | 09320-10501 | CUSHION MODEL K4 | 3 шт. | — | |
|
| 5 | 09320-10055 | CUSHION MODEL K5/K6/K7 | 3 шт. | — | |
|
| 6 | 16640-24F00 | BRACKET, OIL COOLER | 1 шт. | — | |
|
| 7 | 01547-06123 | BOLT | 2 шт. | — | |
|
| 8 | 16460-24F01 | HOSE, OIL COOLER RH | 1 шт. | — | |
|
| 9 | 16470-24F02 | HOSE, OIL COOLER LH | 1 шт. | — | |
|
| 10 | 09280-12012 | O RING (D:2.4,ID:11.8) | 4 шт. | — | |
|
| 11 | 09106-06096 | BOLT, RH (6X16) | 4 шт. | — | |
|
| 12 | 09106-06097 | BOLT, LH (6X20) | 4 шт. | — | |
|
| 13 | 16650-24F01 | GUARD, OIL COOLER Includes Item(s) 13 - 14 | 0 шт. | — | |
|
| 14 | 17765-09F00 | PROTECTOR, CTR | 2 шт. | — | |
|
| 15 | 09352-30503-600 | HOSE (3X5X600) L:600!40 | 4 шт. | — | |
|
