| 1 | 11511-24F00 | PAN, OIL MODEL K4/K5/K6 | 1 шт. | — | |
|
| 2 | 11511-24F01 | PAN, OIL MODEL K7 | 1 шт. | — | |
|
| 3 | 11489-24F01 | GASKET, OIL PAN | 1 шт. | — | |
|
| 4 | 01547-06303 | BOLT | 12 шт. | — | |
|
| 5 | 01547-06403 | BOLT | 2 шт. | — | |
|
| 6 | 09168-06023 | GASKET (5.8X13X1.2) | 1 шт. | — | |
|
| 7 | 09247-14036 | PLUG, OIL DRAIN | 1 шт. | — | |
|
| 8 | 09168-14002 | .GASKET (13.8X18.8X4.8) | 1 шт. | — | |
|
| 9 | 16520-24F00 | STRAINER, ENGINE OIL | 1 шт. | — | |
|
| 10 | 01550-06203 | BOLT | 2 шт. | — | |
|
| 11 | 09280-19008 | O RING (D:2.62,ID:20.3) | 1 шт. | — | |
|
| 12 | 16440-24F00 | VALVE ASSY, OIL RELIEF | 1 шт. | — | |
|
| 13 | 16400-24F01 | PUMP ASSY,ENGINE OIL | 1 шт. | — | |
|
| 14 | 16491-24F00 | O RING,OIL PUMP | 1 шт. | — | |
|
| 15 | 01547-06303 | BOLT | 3 шт. | — | |
|
| 16 | 16321-33E10 | GEAR,OIL PUMP DRIVE (NT:34) | 1 шт. | — | |
|
| 17 | 16331-33E00 | GEAR,OIL PUMP DRIVEN (NT:37) | 1 шт. | — | |
|
| 18 | 09181-12158 | WASHER | 1 шт. | — | |
|
| 19 | 09261-05006 | PIN | 1 шт. | — | |
|
| 20 | 08331-31126 | CIRCLIP | 1 шт. | — | |
|
