| 1 | 17851-24F01 | HOSE, RADIATOR INLET | 1 шт. | — | |
|
| 2 | 17852-24F00 | HOSE, RADIATOR OUTLET | 1 шт. | — | |
|
| 3 | 17853-24F00 | HOSE, CYLINDER INLET | 1 шт. | — | |
|
| 4 | 09402-38511 | CLAMP | 6 шт. | — | |
|
| 5 | 09401-12409 | CLIP, WATER HOSE | 4 шт. | — | |
|
| 6 | 17859-24F00 | CLAMP, RADIATOR INLET HOSE | 1 шт. | — | |
|
| 7 | 01550-06103 | BOLT, HOSE CLAMP | 1 шт. | — | |
|
| 8 | 17854-24F00 | HOSE,WATER BYPASS NO.1 | 1 шт. | — | |
|
| 9 | 17855-24F00 | HOSE, WATER BYPASS NO.2 | 1 шт. | — | |
|
| 10 | 09362-09011 | UNION, BYPASS | 1 шт. | — | |
|
| 11 | 17661-24F00 | COVER, THERMOSTAT | 1 шт. | — | |
|
| 12 | 17670-50F00 | THERMOSTAT, WATER MODEL K4 | 1 шт. | — | |
|
| 13 | 17670-76G00 | THERMOSTAT,WTR (82<-C) MODEL K5/K6/K7 | 1 шт. | — | |
|
| 14 | 01547-06203 | BOLT | 2 шт. | — | |
|
| 15 | 17861-33E10 | CONNECTOR, CYLINDER INLET MODEL K4/K5/K6 | 1 шт. | — | |
|
| 16 | 17861-33E20 | CONNECTOR, CYLINDER WATER MODEL K7 | 1 шт. | — | |
|
| 17 | 17863-33E00 | O RING | 1 шт. | — | |
|
| 18 | 01550-06203 | BOLT | 3 шт. | — | |
|
| 19 | 51827-01A00 | CUSHION, RESERVOIR TANK RH | 1 шт. | — | |
|
| 20 | 53145-48B00 | CUSHION (40X20X5) | 1 шт. | — | |
|
| 21 | 17680-33E00 | SWITCH, RADIATOR FAN Includes Item(s) 20 | 1 шт. | — | |
|
| 22 | 17689-50F00 | O RING | 1 шт. | — | |
|
| 23 | 17910-24F00 | TANK ASSY, RESERVOIR Includes Item(s) 22 | 1 шт. | — | |
|
| 24 | 17932-12C00 | CAP,RESERVOIR TANK | 1 шт. | — | |
|
| 25 | 09136-06022 | SCREW (6X20) | 2 шт. | — | |
|
| 26 | 17981-21810 | HOSE, RESERVOIR TANK INLET | 1 шт. | — | |
|
| 27 | 09401-08411 | CLIP | 2 шт. | — | |
|
| 28 | 17982-38810 | HOSE, OVER FLOW | 1 шт. | — | |
|
| 29 | 09407-18402 | CLAMP, RESERVOIR TANK HOSE | 1 шт. | — | |
|
| 30 | 09407-18402 | CLAMP, RADIATOR OUTLET HOSE | 1 шт. | — | |
|
