| 1 | 62600-24810 | LEVER SET, REAR CUSHION Includes Item(s) 2 - 4 | 0 шт. | — | |
|
| 2 | 09263-20073 | BEARING, FRONT (20X27X30) | 1 шт. | — | |
|
| 3 | 09263-20071 | BEARING, CENTER (20X27X23.5) | 2 шт. | — | |
|
| 4 | 09263-17034 | BEARING, REAR (17X24X26) | 1 шт. | — | |
|
| 5 | 62684-12C00 | SPACER, FRONT (12X20X32) | 1 шт. | — | |
|
| 6 | 08211-12301 | WASHER | 2 шт. | — | |
|
| 7 | 62658-19F00 | BOLT, FRONT (12X78) | 1 шт. | — | |
|
| 8 | 08319-31128 | NUT MODEL K4/K5/K6 | 1 шт. | — | |
|
| 9 | 08319-3112A | NUT MODEL K7 | 1 шт. | — | |
|
| 10 | 62626-24F00 | SPACER, CENTER (12X20X94) | 1 шт. | — | |
|
| 11 | 62621-33D00 | BOLT, CENTER (12X124) | 1 шт. | — | |
|
| 12 | 08319-31128 | NUT MODEL K4/K5/K6 | 1 шт. | — | |
|
| 13 | 08319-3112A | NUT MODEL K7 | 1 шт. | — | |
|
| 14 | 62684-40A10 | SPACER,RR CUSHION LEVER (10X1 | 1 шт. | — | |
|
| 15 | 62641-24F00 | ROD,RR CUSHION | 2 шт. | — | |
|
| 16 | 62626-24F00 | SPACER, ROD (12X20X94) | 1 шт. | — | |
|
| 17 | 62621-33D00 | BOLT, ROD (12X124) | 1 шт. | — | |
|
| 18 | 08319-31128 | NUT MODEL K4/K5/K6 | 1 шт. | — | |
|
| 19 | 08319-3112A | NUT MODEL K7 | 1 шт. | — | |
|
| 20 | 62100-24F40 | ABSORBER ASSY, REAR SHOCK E3,E33 | 0 шт. | — | |
|
| 21 | 62100-24F30 | ABSORBER ASSY, REAR SHOCK E28 | 0 шт. | — | |
|
| 22 | 09103-10033 | BOLT, UPPER (10X70) | 1 шт. | — | |
|
| 23 | 09103-10027 | BOLT, LOWER (10X58) | 1 шт. | — | |
|
| 24 | 08319-31107 | NUT MODEL K4/K5/K6 | 2 шт. | — | |
|
| 25 | 08319-3110A | NUT MODEL K7 | 1 шт. | — | |
|
