| 1 | 69600-33C00 | CYLINDER ASSY, REAR MASTER Includes Item(s) 2 - 9 | 1 шт. | — | |
|
| 2 | 69600-04820 | PISTON / CAP SET | 1 шт. | — | |
|
| 3 | 69691-00A00 | BOOT | 1 шт. | — | |
|
| 4 | 69692-27A30 | YOKE | 1 шт. | — | |
|
| 5 | 69670-48B00 | .ROD,PUSH | 1 шт. | — | |
|
| 6 | 69693-05A00 | NUT | 2 шт. | — | |
|
| 7 | 69672-05A00 | CONNECTOR | 1 шт. | — | |
|
| 8 | 69686-34200 | .O-RING | 1 шт. | — | |
|
| 9 | 02112-74123 | SCREW | 1 шт. | — | |
|
| 10 | 09139-06028 | BOLT (6X20) | 2 шт. | — | |
|
| 11 | 69740-01D02 | TANK ASSY, REAR RESERVOIR Includes Item(s) 12 - 14 | 1 шт. | — | |
|
| 12 | 59667-04700 | DIAPHRAGM | 1 шт. | — | |
|
| 13 | 59669-05D00 | CAP | 1 шт. | — | |
|
| 14 | 69689-04A00 | SCREW | 2 шт. | — | |
|
| 15 | 01550-06123 | BOLT MODEL K4/K5/K6 | 1 шт. | — | |
|
| 16 | 01550-0612B | BOLT MODEL K7 | 1 шт. | — | |
|
| 17 | 69731-24F00 | HOSE, RESERVOIR TANK | 1 шт. | — | |
|
| 18 | 09401-13417 | CLAMP | 2 шт. | — | |
|
| 19 | 69480-24F01 | HOSE, REAR BRAKE | 1 шт. | — | |
|
| 20 | 09360-10041 | BOLT (10X1.00X22) | 2 шт. | — | |
|
| 21 | 09161-10009 | WASHER (10X15X1.5) | 4 шт. | — | |
|
| 22 | 09200-06037 | PIN | 1 шт. | — | |
|
| 23 | 08322-01063 | WASHER MODEL K4/K5/K6 | 1 шт. | — | |
|
| 24 | 08322-0106B | WASHER MODEL K7 | 1 шт. | — | |
|
| 25 | 04111-20158 | PIN, COTTER MODEL K4/K5/K6 | 1 шт. | — | |
|
| 26 | 04111-2015A | PIN, COTTER MODEL K7 | 1 шт. | — | |
|
| 27 | 69750-24F00 | BRACKET, RESERVOIR TANK | 0 шт. | — | |
|
| 28 | 01550-06123 | BOLT MODEL K4/K5/K6 | 1 шт. | — | |
|
| 29 | 01550-0612B | BOLT MODLE K7 | 1 шт. | — | |
|
