| 1 | 64111-33E11-019 | WHEEL, REAR (17XMT6.00) (BLACK) GSX1300RK4/K5/K6 GSX1300RZK4 E28 GSX1300RZK7 | 0 шт. | — | |
|
| 2 | 64111-33E30-BAP | WHEEL, REAR, (17M/CXMT6.00) GSX1300RZK4 E3,E28,E33 GSX1300RZK5 E3,E28,E33 | 0 шт. | — | |
|
| 3 | 64111-33E11-Y6G | WHEEL, REAR (17XMT6.00) (SILVER) GSX1300RZK6 | 0 шт. | — | |
|
| 4 | 64731-33E10 | SPACER, HUB BEARING | 1 шт. | — | |
|
| 5 | 09262-32008 | BEARING (32X58X13) | 2 шт. | — | |
|
| 6 | 09285-38001 | SEAL, RH (38X58X7) | 1 шт. | — | |
|
| 7 | 69211-21E00 | DISC, REAR BRAKE | 1 шт. | — | |
|
| 8 | 09106-08148 | BOLT (8X33) | 5 шт. | — | |
|
| 9 | 69721-24F00 | BRACKET, REAR CALIPER | 0 шт. | — | |
|
| 10 | 64711-33E10 | AXLE, REAR | 1 шт. | — | |
|
| 11 | 04111-40408 | PIN, COTTER MODEL K4/K5/K6 | 1 шт. | — | |
|
| 12 | 04111-4035A | PIN, COTTER MODEL K7 | 1 шт. | — | |
|
| 13 | 09141-25001 | NUT | 1 шт. | — | |
|
| 14 | 64741-33E00 | SPACER, AXLE RH | 1 шт. | — | |
|
| 15 | 64751-24F00 | SPACER, AXLE LH | 1 шт. | — | |
|
| 16 | 64611-33E02 | DRUM, REAR SPROCKET | 0 шт. | — | |
|
| 17 | 64733-33E00 | RETAINER, SPROCKET DRUM | 1 шт. | — | |
|
| 18 | 09262-32007 | BEARING (32X65X17) | 1 шт. | — | |
|
| 19 | 09285-39001 | OIL SEAL (39X65X7) | 1 шт. | — | |
|
| 20 | 64651-31001 | ABSORBER, HUB SHOCK | 6 шт. | — | |
|
| 21 | 64511-24F01 | SPROCKET, REAR (NT:40-530) | 1 шт. | — | |
|
| 22 | 09119-10059 | BOLT (10X38) | 6 шт. | — | |
|
| 23 | 08322-01107 | WASHER | 6 шт. | — | |
|
| 24 | 08319-31107 | NUT MODEL K4/K5/K6 | 6 шт. | — | |
|
| 25 | 08319-3110A | NUT MODEL K7 | 6 шт. | — | |
|
| 26 | 65110-24F10 | TIRE, REAR, 190/50 ZR17 (73W) (BRIDGESTONE) BT56 R RADIAL J | 0 шт. | — | |
|
| 27 | 43130-24A00 | VALVE ASSY,WHEEL RIM (TR412) | 1 шт. | — | |
|
| 28 | 55411-00A00 | BALANCER (10G) MODEL K4 | 1 шт. | — | |
|
| 29 | 55412-00A01 | BALANCER (20G) MODEL K4 | 1 шт. | — | |
|
| 30 | 55411-17G00 | BALANCER, WHEEL, NO.1 MODEL K5/K6/K7 | 1 шт. | — | |
|
| 31 | 55412-17G00 | BALANCER, WHEEL, NO.2 MODEL K5/K6/K7 | 1 шт. | — | |
|
| 32 | 55413-17G00 | BALANCER, WHEEL, NO.3 MODEL K5/K6/K7 | 0 шт. | — | |
|
