| 1 | 45100-24F10-W05 | SEAT ASSY (BLACK) Includes Item(s) 2 - 10 | 1 шт. | — | |
|
| 2 | 45149-45330 | CUSHION | 2 шт. | — | |
|
| 3 | 09321-10011 | CUSHION | 2 шт. | — | |
|
| 4 | 45117-47D00 | CUSHION | 0 шт. | — | |
|
| 5 | 45116-24F10 | BRACKET, SEAT FRONT RH | 1 шт. | — | |
|
| 6 | 09160-06066 | WASHER | 4 шт. | — | |
|
| 7 | 45149-24F01 | CUSHION (10X20X10) | 4 шт. | — | |
|
| 8 | 09180-06310 | SPACER (6.5X10X10) | 4 шт. | — | |
|
| 9 | 45117-24F00 | WASHER, SEAT | 2 шт. | — | |
|
| 10 | 08316-1006A | NUT | 4 шт. | — | |
|
| 11 | 45300-24F10-W05 | SEAT ASSY, PILLION (BLACK) Includes Item(s) 12 | 1 шт. | — | |
|
| 12 | 45213-31300 | CUSHION | 2 шт. | — | |
|
| 13 | 45191-24F00 | BOLT, SEAT FRONT (6X40) | 2 шт. | — | |
|
| 14 | 45220-20A01 | BRACKET, SEAT SUPPORT | 1 шт. | — | |
|
| 15 | 02122-0630B | SCREW | 2 шт. | — | |
|
| 16 | 95700-14810 | LOCK SET,SEAT | 1 шт. | — | |
|
| 17 | 45289-11F00 | PLATE,SEAT LOCK ASSY | 1 шт. | — | |
|
| 18 | 45280-24F00 | CABLE, SEAT LOCK | 1 шт. | — | |
|
| 19 | 45288-14F00 | GUIDE,SEAT LOCK CABLE | 1 шт. | — | |
|
| 20 | 45550-24F10-YAY | BOX, SEAT TAIL (BLACK) FOR YAY | 0 шт. | — | |
|
| 21 | 45550-24F10-YHL | BOX, SEAT TAIL (RED) FOR YHL | 0 шт. | — | |
|
| 22 | 45550-24F10-YKY | BOX, SEAT TAIL (BLUE) FOR YKY; Includes Item(s) 21 | 0 шт. | — | |
|
| 23 | 45213-31300 | CUSHION | 2 шт. | — | |
|
| 24 | 47190-24F00 | WASHER | 2 шт. | — | |
|
| 25 | 46211-24F01-019 | HANDLE, PILLION RIDER (BLACK) | 0 шт. | — | |
|
| 26 | 09103-08373 | BOLT | 4 шт. | — | |
|
| 27 | 47190-24F10 | WASHER, PILLION RIDER HDL | 2 шт. | — | |
|
| 28 | 46217-24F00 | CUSHION,PILLION RIDER HANDLE | 2 шт. | — | |
|
| 29 | 46212-24F11 | HOOK, HANDLE | 2 шт. | — | |
|
| 30 | 09250-05009 | CAP | 2 шт. | — | |
|
