| 1 | 35710-24F30 | LAMP ASSY, REAR COMBINATION Includes Item(s) 2 - 12 | 0 шт. | — | |
|
| 2 | 35712-24F30 | LENS | 1 шт. | — | |
|
| 3 | 35912-24F00 | LENS, LICENSE | 0 шт. | — | |
|
| 4 | 35713-24F00 | GASKET | 1 шт. | — | |
|
| 5 | 35716-48B21 | PLATE NO.1 | 2 шт. | — | |
|
| 6 | 35736-48B21 | PLATE NO.2 | 2 шт. | — | |
|
| 7 | 35765-48B21 | CUSHION | 2 шт. | — | |
|
| 8 | 35718-24F00 | SOCKET & CORD | 1 шт. | — | |
|
| 9 | 03211-04123 | SCREW | 6 шт. | — | |
|
| 10 | 03211-04207 | SCREW | 2 шт. | — | |
|
| 11 | 09471-12083 | BULB (12V,21/5W) | 2 шт. | — | |
|
| 12 | 09471-12216 | BULB (12V,5W) | 1 шт. | — | |
|
| 13 | 03541-0516B | SCREW, REAR COMB | 3 шт. | — | |
|
| 14 | 35726-24F00 | BRACKET, REAR COMB | 1 шт. | — | |
|
| 15 | 03541-0516B | SCREW, BRACKET | 3 шт. | — | |
|
| 16 | 03541-0525B | SCREW, BRACKET | 2 шт. | — | |
|
| 17 | 35927-24F00 | BRACKET, LICENSE PLATE | 1 шт. | — | |
|
| 18 | 09160-06088 | WASHER (6.5X20X1.60) | 2 шт. | — | |
|
| 19 | 02142-0616B | .SCREW | 2 шт. | — | |
|
| 20 | 08316-1006B | NUT | 2 шт. | — | |
|
| 21 | 09321-06026 | CUSHION | 1 шт. | — | |
|
| 22 | 35970-14A20 | REFLECTOR ASSY,REAR SIDE | 2 шт. | — | |
|
| 23 | 35975-24F01 | BRACKET, REAR RH | 0 шт. | — | |
|
| 24 | 35976-24F01 | BRACKET, REAR LH | 0 шт. | — | |
|
| 25 | 02112-0612B | SCREW | 4 шт. | — | |
|
| 26 | 08316-1006B | NUT | 4 шт. | — | |
|
| 27 | 08316-1005B | NUT | 2 шт. | — | |
|
