| 1 | 36610-24F70 | HARNESS, WIRING NO.1 MODEL K4 | 0 шт. | — | |
|
| 2 | 36610-24F90 | HARNESS, WIRING NO.1 MODEL K5/K6/K7; Includes Item(s) 2 - 4 | 0 шт. | — | |
|
| 3 | 09481-10501 | FUSE (10A) | 2 шт. | — | |
|
| 4 | 09481-15501 | FUSE (15A) | 4 шт. | — | |
|
| 5 | 36618-33E00 | .COVER,SPEEDOMETER COUPLER | 1 шт. | — | |
|
| 6 | 36619-24F00 | GUIDE, WIRING HARNESS | 0 шт. | — | |
|
| 7 | 36620-24F10 | HARNESS, WIRING NO.2 | 0 шт. | — | |
|
| 8 | 36856-24F10 | WIRE, INJECTION LEAD | 0 шт. | — | |
|
| 9 | 09404-06429 | CLAMP (L:45) T:1.0 | 4 шт. | — | |
|
| 10 | 09404-06431 | CLAMP (L:65) T:0.7 | 1 шт. | — | |
|
| 11 | 09404-06433 | CLAMP (L:80) | 2 шт. | — | — |
|
| 12 | 09407-14403 | CLAMP (L:125) | 4 шт. | — | |
|
| 13 | 09407-18402 | CLAMP (L:165) | 3 шт. | — | |
|
| 14 | 09407-11402 | CLAMP (L:60) | 1 шт. | — | |
|
| 15 | 09407-14408 | CLAMP (L:90) | 1 шт. | — | |
|
| 16 | 01550-0610B | BOLT, WIRING HARNESS | 2 шт. | — | |
|
| 17 | 36744-24F00 | BRACKET, FUSE BOX | 1 шт. | — | |
|
| 18 | 07120-0510B | SCREW, FUSE BOX | 2 шт. | — | |
|
| 19 | 37000-24810 | LOCK SET | 1 шт. | — | |
|
| 20 | 37000-24830 | LOCK SET E33; Includes Item(s) 15 | 0 шт. | — | |
|
| 21 | 37100-24F00 | LOCK ASSY, STEERING | 1 шт. | — | |
|
| 22 | 09139-08016 | SCREW (8X20) | 2 шт. | — | |
|
| 23 | 37740-24A00 | SWITCH ASSY, STOP LAMP | 1 шт. | — | |
|
| 24 | 09443-06012 | SPRING | 1 шт. | — | |
|
| 25 | 37840-24F00 | SWITCH ASSY, SIDE STAND | 1 шт. | — | |
|
| 26 | 09103-08357 | .BOLT (8X35) | 1 шт. | — | |
|
| 27 | 08316-1008B | .NUT | 1 шт. | — | |
|
| 28 | 38500-24F00 | HORN ASSY | 1 шт. | — | |
|
| 29 | 07120-0612B | BOLT, HORN | 2 шт. | — | |
|
| 30 | 38740-26E00 | RELAY ASSY, FUEL PUMP | 1 шт. | — | |
|
| 31 | 38741-24F00 | BRACKET, FUEL PUMP RLY | 1 шт. | — | |
|
| 32 | 01550-0612B | BOLT, FUEL PUMP | 1 шт. | — | |
|
| 33 | 38740-26E00 | RELAY ASSY, FAN MOTOR | 1 шт. | — | |
|
| 34 | 36851-17E10 | WIRE, OIL PRESSURE | 0 шт. | — | |
|
| 35 | 37146-33E00 | KEY,BLANK OPT | 1 шт. | — | |
|
