| 1 | 11100-MY6-671 | CRANKCASE, R. | 1 шт. | — | |
|
| 2 | 11191-MN1-702 | GASKET, CRANKCASE | 1 шт. | — | |
|
| 2 | 11191-MN1-701 | GASKET, CRANKCASE | 1 шт. | — | |
|
| 3 | 11200-MY6-670 | CRANKCASE, L. | 1 шт. | — | |
|
| 4 | 15421-MN1-671 | SCREEN, OIL FILTER (KOYO) | 1 шт. | — | |
|
| 5 | 15610-MN1-702 | HOSE A, OIL | 1 шт. | — | |
|
| 6 | 15620-MN1-670 | HOSE B, OIL | 1 шт. | — | |
|
| 7 | 15630-MG3-010 | PLATE | 1 шт. | — | |
|
| 8 | 23521-MAN-690 | PLATE, BEARING SETTING | 1 шт. | — | |
|
| 9 | 23523-MG2-790 | WASHER, LOCK (8MM) | 1 шт. | — | |
|
| 10 | 90004-GHB-690 | BOLT, FLANGE (6X32) (NSHF) | 5 шт. | — | |
|
| 11 | 90004-GHB-710 | BOLT, FLANGE (6X40) (NSHF) | 1 шт. | — | |
|
| 12 | 90004-GHB-720 | BOLT, FLANGE (6X45) (NSHF) | 2 шт. | — | |
|
| 13 | 90004-GHB-730 | BOLT, FLANGE (6X50) (NSHF) | 3 шт. | — | |
|
| 14 | 90088-MG3-000 | BOLT, SPECIAL (8MM) | 1 шт. | — | |
|
| 15 | 90131-883-000 | BOLT, DRAIN PLUG (12X15) | 1 шт. | — | |
|
| 15 | 90131-896-650 | BOLT, DRAIN PLUG (12X15) | 1 шт. | — | |
|
| 16 | 91302-MG2-792 | GASKET, RUBBER (10.5MM) | 2 шт. | — | |
|
| 17 | 92900-06022-0E | BOLT 2, STUD (6X22) | 2 шт. | — | |
|
| 18 | 92900-06035-0E | BOLT 2, STUD (6X35) | 1 шт. | — | |
|
| 19 | 94109-12000 | WASHER, DRAIN PLUG (12MM) | 1 шт. | — | |
|
| 20 | 94301-14200 | PIN A, DOWEL (14X20) | 3 шт. | — | |
|
| 21 | 95701-06014-00 | BOLT, FLANGE (6X14) (Honda Code 2410884) | 1 шт. | — | |
|
| 22 | 96001-06016-07 | BOLT, FLANGE (6X16) | 2 шт. | — | |
|
