| 1 | 40510-MEE-010 | CASE, DRIVE CHAIN | 1 шт. | — | |
|
| 2 | 40535-MAL-G01 | MASTER LINK SET (DAIDO) | 1 шт. | — | |
|
| 3 | 40541-MFJ-D02 | MASTER LINK SET (RK EXCEL) | 1 шт. | — | |
|
| 4 | 40540-MAL-G01 | CHAIN, DRIVE (DID525HV-120ZB) (DAIDO) (STANDARD LINK 108L) | 1 шт. | — | |
|
| 5 | 40540-MFJ-D02 | CHAIN, DRIVE (525ROZ6-120LJFZ) (RK EXCEL) (STANDARD LINK 112L) | 1 шт. | — | |
|
| 6 | 42305-MFL-000 | COLLAR, L. RR. AXLE | 1 шт. | — | |
|
| 7 | 42306-MFL-000 | COLLAR, R. RR. AXLE | 1 шт. | — | |
|
| 8 | 52101-MFJ-D00 | BOLT, SWINGARM PIVOT | 1 шт. | — | |
|
| 9 | 52102-MJC-A00 | COLLAR, SWINGARM PIVOT | 1 шт. | — | |
|
| 10 | 52106-MGC-D30 | COLLAR B, PIVOT | 2 шт. | — | |
|
| 11 | 52108-MFJ-D00 | BOLT, R. PIVOT ADJUSTING | 1 шт. | — | |
|
| 12 | 52170-MFJ-D00 | SLIDER, CHAIN | 1 шт. | — | |
|
| 13 | 52171-MFJ-D00 | WASHER, CHAIN SLIDER | 2 шт. | — | |
|
| 14 | 52200-MFJ-A51 | SWINGARM SUB-ASSY., RR. | 1 шт. | — | |
|
| 15 | 52463-MJC-A00 | COLLAR, CUSHION CONNECTING ROD | 1 шт. | — | |
|
| 16 | 90105-MY9-000 | BOLT, FLANGE (6X18) | 3 шт. | — | |
|
| 17 | 90106-MFJ-A50 | BOLT, HEX. (8X50) | 2 шт. | — | |
|
| 18 | 90113-MAS-E00 | BOLT, FLANGE (6MM) | 3 шт. | — | |
|
| 19 | 90306-MCS-G01 | NUT, U (18MM) | 1 шт. | — | |
|
| 20 | 90309-357-000 | NUT, HEX. (10MM) | 2 шт. | — | |
|
| 21 | 90355-MFJ-D00 | NUT, SWINGARM PIVOT | 1 шт. | — | |
|
| 22 | 90401-KZ4-890 | WASHER (18X32X2) | 1 шт. | — | |
|
| 23 | 90485-MB2-000 | WASHER (6MM) | 1 шт. | — | |
|
| 24 | 91071-KV3-005 | BEARING, NEEDLE (KOYO) | 1 шт. | — | |
|
| 25 | 91071-MBW-E11 | BEARING, NEEDLE | 1 шт. | — | |
|
| 26 | 91071-MR7-003 | BEARING, NEEDLE | 1 шт. | — | |
|
| 27 | 91072-MR7-003 | BEARING, RADIAL BALL (20X37X9) | 1 шт. | — | |
|
| 28 | 91202-MR7-003 | DUST SEAL (28X37X4) | 2 шт. | — | |
|
| 29 | 91262-KV3-831 | DUST SEAL (17X24X5) (ARAI) | 2 шт. | — | |
|
| 30 | 94520-37000 | CIRCLIP (INNER) (37MM) | 1 шт. | — | |
|
