| 1 | 18291-KZ1-670 | GASKET, EX. PIPE | 1 шт. | — | |
|
| 2 | 18310-KSE-000 | MUFFLER | 1 шт. | — | |
|
| 3 | 18313-KSE-300 | BODY, MUFFLER | 1 шт. | — | |
|
| 4 | 18320-KSE-000 | PIPE, EX. | 1 шт. | — | |
|
| 5 | 18323-KSE-A50 | PROTECTOR, EX. PIPE | 1 шт. | — | |
|
| 6 | 18324-MEB-670 | RIVET, BLIND (4.8) | 14 шт. | — | |
|
| 7 | 18336-KSE-300 | PACK A, GLASS WOOL | 1 шт. | — | |
|
| 8 | 18345-KSE-300 | PACK B, GLASS WOOL | 1 шт. | — | |
|
| 9 | 18350-KSE-000 | MUFFLER, FR. | 1 шт. | — | |
|
| 10 | 18350-KSE-305 | MUFFLER, FR. (COO) | 1 шт. | — | |
|
| 11 | 18351-KSE-000 | MUFFLER, RR. (96DB) | 1 шт. | — | |
|
| 12 | 18351-KSE-305 | MUFFLER, RR. (96DB) (COO) | 1 шт. | — | |
|
| 13 | 18373-MG7-701 | BAND, R. MUFFLER | 1 шт. | — | |
|
| 14 | 18374-KE8-000 | BAND, L. MUFFLER | 1 шт. | — | |
|
| 15 | 18392-MK4-000 | GASKET, MUFFLER | 1 шт. | — | |
|
| 16 | 19508-KA3-710 | NUT, SPRING (6MM) | 2 шт. | — | |
|
| 17 | 90123-KZ4-J40 | BOLT, FLANGE (8X18) | 1 шт. | — | |
|
| 18 | 90123-MEN-670 | BOLT, FLANGE (8X16) | 1 шт. | — | |
|
| 19 | 90124-KZ4-J40 | BOLT, FLANGE (8X35) | 1 шт. | — | |
|
| 20 | 90170-MEB-670 | BOLT, SPECIAL (6MM) | 2 шт. | — | |
|
| 21 | 90355-427-770 | NUT, FLANGE (7MM) | 2 шт. | — | |
|
| 22 | 94101-05000 | WASHER, PLAIN (5MM) | 6 шт. | — | |
|
| 23 | 94101-08000 | WASHER, PLAIN (8MM) | 1 шт. | — | |
|
| 24 | 94102-08800 | WASHER, PLAIN (8MM) | 1 шт. | — | |
|
