| 1 | 06420-KSE-840 | SPOKE SET, RR. | 32 шт. | — | |
|
| 2 | 41201-GBF-K10 | SPROCKET, FINAL (56T) (SUNSTAR) (Optional). | 1 шт. | — | |
|
| 3 | 41201-GBF-860 | SPROCKET, FINAL (55T) (SUNSTAR) (Optional). | 1 шт. | — | |
|
| 4 | 41201-KSE-840 | SPROCKET, FINAL DRIVEN (56T) | 1 шт. | — | |
|
| 5 | 41202-GBF-860 | SPROCKET, FINAL (57T) (SUNSTAR) (Optional). | 1 шт. | — | |
|
| 6 | 42301-KSE-000 | AXLE, RR. WHEEL | 1 шт. | — | |
|
| 7 | 42305-KSE-000 | COLLAR, RR. AXLE | 2 шт. | — | |
|
| 8 | 42311-KSE-000 | COLLAR, RR. WHEEL SIDE | 2 шт. | — | |
|
| 9 | 42620-KSE-000 | COLLAR, RR. WHEEL DISTANCE | 1 шт. | — | |
|
| 10 | 42635-KSE-670 | HUB SUB-ASSY., RR. | 1 шт. | — | |
|
| 11 | 42650-KSE-840 | WHEEL SUB-ASSY., RR. | 1 шт. | — | |
|
| 12 | 42701-KSE-841 | RIM, RR. WHEEL | 1 шт. | — | |
|
| 13 | 42711-KSE-F61 | TIRE, RR. (90/100-16 52M) (DUNLOP) | 1 шт. | — | |
|
| 14 | 42712-GBF-861 | TUBE, TIRE (90/100-16) (DUNLOP) | 1 шт. | — | |
|
| 15 | 42713-GBF-861 | FLAP, TIRE (1.85X16) (DUNLOP) | 1 шт. | — | |
|
| 16 | 42714-KA3-710 | CAP, VALVE | 1 шт. | — | |
|
| 17 | 43351-KSE-000 | DISK, RR. BRAKE | 1 шт. | — | |
|
| 18 | 42715-KA2-680 | STOPPER, BEAD (1.85) STOPPER, BEAD (1.85B) | 1 шт. | — | |
|
| 19 | 90105-KAE-870 | BOLT, DISK (6X17) | 4 шт. | — | |
|
| 20 | 90125-KA4-000 | SCREW, FLAT (8X31) | 4 шт. | — | |
|
| 21 | 90305-GW2-711 | NUT, U (16MM) | 1 шт. | — | |
|
| 22 | 90309-ML3-791 | NUT, U (8MM) (FUSE RASHI) | 4 шт. | — | |
|
| 23 | 90465-MC4-000 | WASHER (8MM) | 4 шт. | — | |
|
| 24 | 90501-GBM-750 | WASHER (16MM) | 1 шт. | — | |
|
| 25 | 91051-KSE-003 | BEARING, RADIAL BALL (6003) | 3 шт. | — | |
|
| 26 | 91205-VM6-003 | DUST SEAL (23X35X7) | 2 шт. | — | |
|
| 27 | 94001-08000-0S | NUT, HEX. (8MM) | 1 шт. | — | |
|
| 28 | 94111-08000 | WASHER, SPRING (8MM) | 1 шт. | — | |
|
| 29 | 94520-35000 | CIRCLIP (INNER) (35MM) | 1 шт. | — | |
|
