| 1 | 23210-KSE-670 | MAINSHAFT (14T) | 1 шт. | — | |
|
| 2 | 23221-KSE-670 | COUNTERSHAFT | 1 шт. | — | |
|
| 3 | 23411-KSE-670 | GEAR, COUNTERSHAFT LOW (31T) | 1 шт. | — | |
|
| 4 | 23421-KSE-670 | GEAR, MAINSHAFT SECOND (17T) | 1 шт. | — | |
|
| 5 | 23422-KSE-670 | COLLAR (16.5MM) | 1 шт. | — | |
|
| 6 | 23431-KSE-670 | GEAR, COUNTERSHAFT SECOND (28T) | 1 шт. | — | |
|
| 7 | 23432-KSE-670 | COLLAR (20MM) | 2 шт. | — | |
|
| 8 | 23441-KSE-670 | GEAR, MAINSHAFT THIRD (22T) | 1 шт. | — | |
|
| 9 | 23451-KSE-670 | GEAR, COUNTERSHAFT THIRD (29T) | 1 шт. | — | |
|
| 10 | 23461-KSE-670 | GEAR, MAINSHAFT FOURTH (19T) | 1 шт. | — | |
|
| 11 | 23471-KSE-670 | GEAR, COUNTERSHAFT FOURTH (21T) | 1 шт. | — | |
|
| 12 | 23481-KSE-A70 | GEAR, MAINSHAFT FIFTH (23T) | 1 шт. | — | |
|
| 13 | 23483-KSE-670 | COLLAR (18MM) | 1 шт. | — | |
|
| 14 | 23491-KSE-670 | GEAR, COUNTERSHAFT FIFTH (22T) | 1 шт. | — | |
|
| 15 | 23512-KSE-670 | COLLAR, SPLINE (18X11.7) | 1 шт. | — | |
|
| 16 | 23801-KSE-670 | SPROCKET, DRIVE (15T) | 1 шт. | — | |
|
| 17 | 23802-KSE-670 | PLATE, DRIVE SPROCKET FIXING | 1 шт. | — | |
|
| 18 | 90071-MF5-000 | BOLT, FLANGE SOCKET (6X14) | 2 шт. | — | |
|
| 19 | 90084-041-000 | BOLT, DRIVE SPROCKET FIXING | 2 шт. | — | |
|
| 20 | 90401-KCZ-000 | WASHER, THRUST (18MM) | 1 шт. | — | |
|
| 21 | 90401-KSE-670 | WASHER, THRUST INVOLUTE (18X23X1.6) | 2 шт. | — | |
|
| 22 | 90403-KSE-670 | WASHER, THRUST INVOLUTE (20X26X1) | 1 шт. | — | |
|
| 23 | 90441-KRM-840 | PLATE, BEARING HOLDER | 2 шт. | — | |
|
| 24 | 90451-107-000 | WASHER, THRUST (15MM) | 1 шт. | — | |
|
| 25 | 90452-437-000 | WASHER, THRUST (16.5MM) | 1 шт. | — | |
|
| 26 | 90457-HB3-000 | WASHER, THRUST (15X1) | 1 шт. | — | |
|
| 27 | 90554-728-940 | WASHER, THRUST (27X20X1.0) | 3 шт. | — | |
|
| 28 | 90601-030-000 | CIRCLIP (18MM) | 2 шт. | — | |
|
| 29 | 90601-459-000 | CIRCLIP (OUTER) (20MM) | 1 шт. | — | |
|
| 30 | 91004-MT3-003 | BEARING, RADIAL BALL (20X47X10.5) | 1 шт. | — | |
|
| 31 | 91008-KSE-671 | BEARING, RADIAL BALL (6002U) | 1 шт. | — | |
|
| 32 | 91202-KCY-761 | OIL SEAL (20X30X7) | 1 шт. | — | |
|
| 33 | 96120-62030-00 | BEARING, RADIAL BALL (6203) | 1 шт. | — | |
|
| 34 | 96140-62020 | BEARING, RADIAL BALL (6202U) | 1 шт. | — | |
|
| 35 | 96140-62020-00 | BEARING, RADIAL BALL (6202U) | 1 шт. | — | |
|
