| 1 | 16180-HC4-003 | VALVE, ONE-WAY | 1 шт. | — | |
|
| 2 | 16185-MKE-A50 | RUBBER, VALVE | 1 шт. | — | |
|
| 3 | 17310-MKE-A51 | CANISTER | 1 шт. | — | |
|
| 4 | 17312-MKE-A50 | TUBE (CANISTER-PCSV) | 1 шт. | — | |
|
| 5 | 17313-MKE-A50 | TUBE, PURGE CONTROL VALVE JOINT | 1 шт. | — | |
|
| 6 | 17314-MKE-A50 | TUBE, JOINT-INSULATOR | 1 шт. | — | |
|
| 7 | 17315-MKE-A50 | TUBE, AIR | 1 шт. | — | |
|
| 8 | 17316-MKE-A50 | RUBBER, CANISTER | 1 шт. | — | |
|
| 9 | 17317-MKE-A50 | STAY A, CANISTER | 1 шт. | — | |
|
| 10 | 17318-MKE-A50 | STAY B, CANISTER | 1 шт. | — | |
|
| 11 | 17319-MKE-A50 | TUBE, DRAIN | 1 шт. | — | |
|
| 12 | 17321-MKE-A50 | GUARD, CANISTER | 1 шт. | — | |
|
| 13 | 19126-KM1-010 | JOINT, TUBE | 1 шт. | — | |
|
| 14 | 36162-MKE-A51 | VALVE, PURGE CONTROL SOLENOID | 1 шт. | — | |
|
| 15 | 90651-HN6-A51 | CLAMP, TUBE (12.0) | 2 шт. | — | |
|
| 16 | 95002-02070 | CLIP, TUBE (B7) CLIP, TUBE (B6.5) | 5 шт. | — | |
|
| 17 | 95002-02120 | CLIP, TUBE (B12) | 2 шт. | — | |
|
| 18 | 95002-02130 | CLIP, TUBE (B12.5) | 1 шт. | — | |
|
| 19 | 95005-35001-50M | BULK HOSE, VACUUM (3.5X1000) (3.5X350) | 1 шт. | — | |
|
| 20 | 96300-06018-00 | BOLT, FLANGE (6X18) | 2 шт. | — | |
|
