| 1 | 18291-MEB-670 | GASKET, EX. PIPE | 2 шт. | — | |
|
| 2 | 18293-MCA-A20 | RUBBER, PROTECTOR GASKET | 3 шт. | — | |
|
| 3 | 18300-MKE-A50 | MUFFLER ASSY. | 1 шт. | — | |
|
| 4 | 18306-MKE-A50 | CAP, TAIL | 1 шт. | — | |
|
| 5 | 18316-KFT-620 | RUBBER, PROTECTOR | 1 шт. | — | |
|
| 6 | 18317-MKE-A50 | ARRESTER, SPARK | 1 шт. | — | |
|
| 7 | 18320-MKE-A50 | PIPE, EX. | 1 шт. | — | |
|
| 8 | 18323-MKE-A00 | PROTECTOR, EX. PIPE | 1 шт. | — | |
|
| 9 | 18327-KRN-A80 | STAY, EX. PIPE PROTECTOR | 1 шт. | — | |
|
| 10 | 18328-MKE-A50 | STAY, RR. EX. PIPE PROTECTOR | 1 шт. | — | |
|
| 11 | 18340-MKE-A50 | GUARD, HEAT | 1 шт. | — | |
|
| 12 | 18345-MBT-610 | RUBBER, PROTECTOR MOUNTING | 3 шт. | — | |
|
| 13 | 18365-MKE-A50 | COVER, RR. MUFFLER | 1 шт. | — | |
|
| 14 | 18366-MKE-A50 | GUARD, RR. HEAT (A) | 1 шт. | — | |
|
| 15 | 18374-ML0-000 | BAND, L. EX. PIPE (RIGHT SIDE) | 1 шт. | — | |
|
| 16 | 18392-HA7-710 | GASKET, EX. | 1 шт. | — | |
|
| 17 | 19508-KA3-710 | NUT, SPRING (6MM) | 2 шт. | — | |
|
| 18 | 19509-MM5-003 | CLAMP, R. RADIATOR HOSE | 2 шт. | — | |
|
| 19 | 83505-KGB-610 | COLLAR, COVER MOUNTING | 1 шт. | — | |
|
| 20 | 83512-KA4-700 | RUBBER, SIDE COVER (PD) | 3 шт. | — | |
|
| 21 | 90101-KCE-000 | BOLT, FLANGE (6X10) | 3 шт. | — | |
|
| 22 | 96001-06010-07 | BOLT, FLANGE (6X10) | 3 шт. | — | |
|
| 23 | 90101-MKE-A00 | BOLT, SPECIAL (5X12) | 3 шт. | — | |
|
| 24 | 90109-MKE-A50 | BOLT, FLANGE (8X25) (SH) | 1 шт. | — | |
|
| 25 | 90110-MKE-A50 | BOLT, FLANGE (8X20) (SH) | 1 шт. | — | |
|
| 26 | 90112-MKE-A50 | BOLT, SPECIAL (6X22) | 1 шт. | — | |
|
| 27 | 90113-KTA-920 | SCREW, PAN (6X12) | 2 шт. | — | |
|
| 28 | 90124-MKE-A50 | BOLT, FLANGE (8X32) (SH) | 1 шт. | — | |
|
| 29 | 90170-MEB-670 | BOLT, SPECIAL (6MM) | 2 шт. | — | |
|
| 30 | 90304-ME1-670 | NUT, CAP (8MM) | 2 шт. | — | |
|
| 31 | 94101-05400 | WASHER, PLAIN (5MM) | 3 шт. | — | |
|
| 32 | 94102-08400 | WASHER, PLAIN (8MM) | 1 шт. | — | |
|
| 33 | 94103-08400 | WASHER, PLAIN (8MM) | 1 шт. | — | |
|
