| 1 | 35700-MKE-A51 | SWITCH ASSY., SIDE STAND | 1 шт. | — | |
|
| 2 | 50530-MKE-A50 | BAR, SIDE STAND | 1 шт. | — | |
|
| 3 | 50538-MKE-A10 | HOOK, SIDE STAND SPRING | 1 шт. | — | |
|
| 4 | 50540-MKE-A50 | SPRING ASSY., SIDE STAND | 1 шт. | — | |
|
| 5 | 50547-MKE-A50 | GUARD, SIDE STAND SWITCH | 1 шт. | — | |
|
| 6 | 50603-KZ4-J40 | PIN, STEP JOINT | 2 шт. | — | |
|
| 7 | 50610-MEN-B10 | BRACKET, R. STEP | 1 шт. | — | |
|
| 8 | 50611-MKE-A50 | BRACKET, L. STEP | 1 шт. | — | |
|
| 9 | 50617-KZ4-J40 | SPRING, R. STEP RETURN | 1 шт. | — | |
|
| 10 | 50618-KZ4-J40 | SPRING, L. STEP RETURN | 1 шт. | — | |
|
| 11 | 50660-MKE-A70 | ARM, R. STEP | 1 шт. | — | |
|
| 12 | 50670-MKE-A70 | ARM, L. STEP | 1 шт. | — | |
|
| 13 | 90021-GHB-610 | BOLT, FLANGE (6X10) | 2 шт. | — | |
|
| 14 | 90106-MKE-AJ0 | BOLT, STEP (12MM) | 2 шт. | — | |
|
| 15 | 90110-MEN-B10 | BOLT, STEP BRACKET | 2 шт. | — | |
|
| 16 | 90118-MKE-A50 | BOLT, SIDE STAND PIVOT | 1 шт. | — | |
|
| 17 | 90147-MCE-950 | BOLT, SPECIAL (6X16) | 1 шт. | — | |
|
| 18 | 90304-GE8-003 | NUT, U (10MM) NUT, SELF-LOCK (10MM) | 1 шт. | — | |
|
| 19 | 90679-SG9-E01 | BAND, SUCTION HOSE (BLACK) (Honda Code 3522752) | 1 шт. | — | |
|
| 20 | 91541-S0A-003 | CLIP, HARNESS BAND (145MM) (BLACK) | 1 шт. | — | |
|
| 21 | 94102-08800 | WASHER, PLAIN (8MM) | 2 шт. | — | |
|
| 22 | 94201-25150 | PIN, COTTER (2.5MM) | 2 шт. | — | |
|
| 23 | 94201-25200 | PIN, COTTER (2.5MM) | 2 шт. | — | |
|
| 24 | 94201-25250 | PIN, COTTER (2.5MM) | 2 шт. | — | |
|
| 25 | 94201-25300 | PIN, COTTER (2.5MM) | 2 шт. | — | |
|
