| 1-1 | 47311-49J00-YU1 | COVER, FRAME CENTER (YELLOW) FOR YU1 | 1 шт. | — | |
|
| 1-2 | 47311-49J00-YUD | COVER, FRAME CENTER (GRAY) FOR A8W | 1 шт. | — | |
|
| 2 | 09139-06188 | SCREW (6X12) | 1 шт. | — | |
|
| 3 | 01550-0612A | BOLT | 2 шт. | — | |
|
| 4-1 | 47121-49J00-YU1 | COVER, FRAME UPPER RH (YELLOW FOR YU1 | 1 шт. | — | |
|
| 4-2 | 47121-49J00-YUD | COVER, FRAME UPPER RH (GRAY) FOR A8W | 1 шт. | — | |
|
| 5 | 47131-49J00 | COVER, FRAME INNER RH | 1 шт. | — | |
|
| 6-1 | 47221-49J00-YU1 | COVER, FRAME UPPER LH (YELLOW FOR YU1 | 1 шт. | — | |
|
| 6-2 | 47221-49J00-YUD | COVER, FRAME UPPER LH (GRAY) FOR A8W | 1 шт. | — | |
|
| 7 | 09320-08018 | CUSHION | 2 шт. | — | |
|
| 8 | 09320-08028 | CUSHION (8X26X7) | 2 шт. | — | |
|
| 9 | 03541-0516A | SCREW | 4 шт. | — | |
|
| 10 | 09135-08012 | BOLT (8X25) | 2 шт. | — | |
|
| 11 | 09169-08045 | WASHER | 2 шт. | — | |
|
| 12-1 | 47111-49J00-30H | COVER, FRAME RH (WHITE) FOR YU1 | 1 шт. | — | |
|
| 12-2 | 47111-49J00-019 | COVER, FRAME RH (BLACK) FOR A8W | 1 шт. | — | |
|
| 13-1 | 47211-49J00-30H | COVER, FRAME LH (WHITE) FOR YU1 | 1 шт. | — | |
|
| 13-2 | 47211-49J00-019 | COVER, FRAME LH (BLACK) FOR A8W | 1 шт. | — | |
|
| 14 | 47161-08G00 | CUSHION | 1 шт. | — | |
|
| 15 | 09320-08029 | CUSHION | 2 шт. | — | |
|
| 16 | 09139-06169 | SCREW (6X16) | 2 шт. | — | |
|
| 17 | 68135-49J00-GYY | EMBLEM, FRAME COVER RH | 1 шт. | — | |
|
| 17 | 68135-49J00-GYY | (WHITE/GRAY) | 0 шт. | — | |
|
| 18 | 68145-49J00-GYY | EMBLEM, FRAME COVER LH | 1 шт. | — | |
|
| 18 | 68145-49J00-GYY | (WHITE/GRAY) | 0 шт. | — | |
|
| 19-1 | 68171-28H00-YHG | EMBLEM "SUZUKI" (GRAY) FOR YU1 | 1 шт. | — | |
|
| 19-2 | 68171-28H00-YD8 | EMBLEM "SUZUKI" (SILVER) FOR A8W | 1 шт. | — | |
|
| 20 | SPECIAL NOTE | A8W=019(BLACK),YUD(GRAY) | 0 шт. | — | |
|
| 20 | SPECIAL NOTE | COLOR : | 0 шт. | — | |
|
