| 1 | 40510-K1T-E10 | CASE, DRIVE CHAIN | 1 шт. | — | |
|
| 2 | 40540-KYJ-902 | CHAIN, DRIVE (DID520VF-120ZB) (DAIDO) (STANDARD LINK 108L) | 1 шт. | — | |
|
| 3 | 40545-KYJ-902 | MASTER LINK (DAIDO) | 1 шт. | — | |
|
| 4 | 52101-KZZ-900 | BOLT, SWINGARM PIVOT | 1 шт. | — | |
|
| 5 | 52141-KZZ-900 | COLLAR, CENTER PIVOT DISTANCE | 1 шт. | — | |
|
| 6 | 52144-356-005 | CAP, SWINGARM DUST SEAL (NOK) | 2 шт. | — | |
|
| 7 | 52146-KV6-010 | GUIDE, CHAIN | 1 шт. | — | |
|
| 8 | 52147-KV6-010 | SLIDER, CHAIN GUIDE | 1 шт. | — | |
|
| 9 | 52161-KZZ-900 | CAP, RR. SWINGARM | 4 шт. | — | |
|
| 10 | 52170-K1T-E10 | SLIDER, CHAIN | 1 шт. | — | |
|
| 11 | 52171-MAN-620 | WASHER, CHAIN SLIDER | 3 шт. | — | |
|
| 12 | 52200-K1T-E10 | SWINGARM SUB-ASSY., RR. | 1 шт. | — | |
|
| 13 | 90103-KZZ-900 | BOLT, FLANGE (6X20) | 2 шт. | — | |
|
| 14 | 90107-K28-910 | BOLT-WASHER (5X16) | 1 шт. | — | |
|
| 15 | 90107-MJP-G50 | SCREW, PAN (5X12) | 4 шт. | — | |
|
| 16 | 90111-KZZ-900 | BOLT, FLANGE (6MM) | 3 шт. | — | |
|
| 17 | 90112-KZZ-900 | BOLT, HEX. (8X47.5) | 2 шт. | — | |
|
| 18 | 90115-KZZ-900 | SCREW, FLAT (6X53) | 2 шт. | — | |
|
| 19 | 90301-KGH-901 | NUT, U (6MM) (FUJI SEIMITSU) | 2 шт. | — | |
|
| 20 | 90305-KCJ-951 | NUT, U (14MM) (FUJI SEIMITSU) | 1 шт. | — | |
|
| 21 | 90309-357-000 | NUT, HEX. (10MM) | 2 шт. | — | |
|
| 22 | 90503-K1T-E10 | COLLAR (5.3X12X5.8) | 1 шт. | — | |
|
| 23 | 91070-GC4-601 | BEARING, NEEDLE (20X26X20) (TOYO) BEARING, SWINGARM PIVOT | 2 шт. | — | |
|
| 24 | 91254-KS6-003 | DUST SEAL (20X26X4.5) (ARAI) | 2 шт. | — | |
|
| 25 | 94103-05700 | WASHER, PLAIN (5MM) | 1 шт. | — | |
|
