| 1 | 19014-KEA-003 | NUT, SETTING (6MM) | 2 шт. | — | |
|
| 2 | 19021-MEN-A30 | RUBBER, RADIATOR (UPPER) | 2 шт. | — | |
|
| 3 | 19033-MKE-A50 | GRILLE, R. RADIATOR | 1 шт. | — | |
|
| 4 | 19034-MKE-A50 | GRILLE, L. RADIATOR | 1 шт. | — | |
|
| 5 | 19037-GEE-710 | CAP, RADIATOR | 1 шт. | — | |
|
| 6 | 19046-PAA-A00 | LABEL, RADIATOR CAP | 1 шт. | — | |
|
| 7 | 19051-KA3-830 | RUBBER, RADIATOR MOUNTING | 4 шт. | — | |
|
| 8 | 19052-MAC-680 | COLLAR, RADIATOR MOUNTING | 4 шт. | — | |
|
| 9 | 19061-MKE-A50 | HOSE A, WATER | 1 шт. | — | |
|
| 10 | 19062-MKE-A50 | HOSE B, WATER | 1 шт. | — | |
|
| 11 | 19063-MKE-A50 | HOSE C, WATER | 1 шт. | — | |
|
| 12 | 19064-MKE-A50 | HOSE D, WATER | 1 шт. | — | |
|
| 13 | 19065-MKE-A50 | HOSE E, WATER | 1 шт. | — | |
|
| 14 | 19070-MEC-003 | PETCOCK ASSY., DRAIN | 1 шт. | — | |
|
| 15 | 19071-MEC-003 | PETCOCK, DRAIN | 1 шт. | — | |
|
| 16 | 19100-MKE-A50 | RADIATOR ASSY., R. | 1 шт. | — | |
|
| 17 | 19160-MKE-A50 | RADIATOR ASSY., L. | 1 шт. | — | |
|
| 18 | 19502-MKE-A00 | CLAMP, WATER HOSE (D27) | 1 шт. | — | |
|
| 19 | 19503-MKE-A50 | JOINT, HOSE THREE WAY | 1 шт. | — | |
|
| 20 | 19505-MKE-A50 | CLAMP, WATER HOSE (D21) | 4 шт. | — | |
|
| 21 | 19506-KS6-700 | CLAMP B, WATER HOSE | 5 шт. | — | |
|
| 22 | 90020-GHB-680 | BOLT, FLANGE (6X25) | 4 шт. | — | |
|
| 23 | 90201-KPR-901 | NUT, CLIP (6MM) | 2 шт. | — | |
|
| 24 | 90403-KA3-830 | WASHER, RADIATOR MOUNTING | 4 шт. | — | |
|
| 25 | 91353-MEC-003 | O-RING (9.8X1.9) | 1 шт. | — | |
|
