| 1 | 06430-GGZ-J00 | SHOE SET, BRAKE (JB) | 1 шт. | — | |
|
| 2 | 40543-K0G-900 | ADJUSTER, CHAIN | 1 шт. | — | |
|
| 3 | 42313-K0G-T20 | COLLAR, RR. | 1 шт. | — | |
|
| 4 | 43100-KWW-640ZD | PANEL, RR. *NH303M* | 1 шт. | — | |
|
| 5 | 43141-K0G-900 | CAM, RR. BRAKE | 1 шт. | — | |
|
| 6 | 43151-110-000 | SPRING, BRAKE SHOE (SEE KIT P/N--END OF BLOCK) | 2 шт. | — | |
|
| 7 | 43410-K41-N00 | ARM, RR. BRAKE | 1 шт. | — | |
|
| 8 | 43434-ME1-670 | RUBBER, STOPPER ARM | 1 шт. | — | |
|
| 9 | 45134-250-000 | DUST SEAL, BRAKE CAM | 1 шт. | — | |
|
| 10 | 45145-KFM-900 | INDICATOR, FR. BRAKE (FOR RR.) | 1 шт. | — | |
|
| 11 | 90127-KWB-600 | BOLT A, BRAKE STOPPER | 1 шт. | — | |
|
| 12 | 90301-KGH-901 | NUT, U (6MM) (FUJI SEIMITSU) | 1 шт. | — | |
|
| 13 | 90302-KZV-J00 | NUT, SPECIAL (6MM) | 1 шт. | — | |
|
| 14 | 90306-K0G-901 | NUT, U (12MM) | 1 шт. | — | |
|
| 15 | 90501-K0G-900 | WASHER, RR. AXLE | 1 шт. | — | |
|
| 16 | 90505-425-000 | WASHER (8MM) WASHER A, HANDLE HOLDER | 1 шт. | — | |
|
| 17 | 90524-030-000 | WASHER A, HANDLE HOLDER SETTING | 1 шт. | — | |
|
| 18 | 90559-K0G-900 | PLATE, SWINGARM SIDE | 1 шт. | — | |
|
| 19 | 94001-06000-0S | NUT, HEX. (6MM) | 1 шт. | — | |
|
| 20 | 94001-06200-0S | NUT, HEX. (6MM) | 1 шт. | — | |
|
| 21 | 94001-08000-0S | NUT, HEX. (8MM) | 1 шт. | — | |
|
| 22 | 94201-20150 | PIN, COTTER (2.0X15) | 1 шт. | — | |
|
| 23 | 95701-06035-00 | BOLT, FLANGE (6X35) | 1 шт. | — | |
|
