| 1 | 23211-K0G-T20 | MAINSHAFT (14T) | 1 шт. | — | |
|
| 2 | 23221-K1M-T00 | COUNTERSHAFT (19T) | 1 шт. | — | |
|
| 3 | 23415-K0G-T20 | BUSH (15MM) | 1 шт. | — | |
|
| 4 | 23421-K0G-T20 | GEAR (35T) | 1 шт. | — | |
|
| 5 | 23422-K0G-T20 | BUSH (17MM) | 1 шт. | — | |
|
| 6 | 23431-K0G-T20 | GEAR (20T) | 1 шт. | — | |
|
| 7 | 23432-K1M-T00 | BUSH (12MM) | 1 шт. | — | |
|
| 8 | 23441-K0G-T20 | GEAR (31T) | 1 шт. | — | |
|
| 9 | 23451-K0G-T20 | GEAR (20T) | 1 шт. | — | |
|
| 10 | 23452-K1M-T00 | BUSH (20MM) | 1 шт. | — | |
|
| 11 | 23461-K0G-T20 | GEAR (23T) | 1 шт. | — | |
|
| 12 | 23471-K0G-T20 | GEAR (26T) | 1 шт. | — | |
|
| 13 | 23481-K0G-T20 | GEAR (24T) | 1 шт. | — | |
|
| 14 | 23800-K0G-900 | SPROCKET, DRIVE (14T) | 1 шт. | — | |
|
| 15 | 23802-GN5-910 | PLATE, FIXING | 1 шт. | — | |
|
| 16 | 23911-K1M-T00 | COLLAR, LOCK PLATE | 1 шт. | — | |
|
| 17 | 90407-KWW-740 | WASHER (6.2X19X2.3) | 2 шт. | — | |
|
| 18 | 90412-187-000 | WASHER, THRUST (15MM) | 1 шт. | — | |
|
| 19 | 90412-K56-N00 | WASHER, SPECIAL (15MM) | 1 шт. | — | |
|
| 20 | 90452-KGH-900 | WASHER, SPECIAL (12MM) | 1 шт. | — | |
|
| 21 | 90452-KRM-840 | WASHER, SPLINE (17X23X1.6) | 1 шт. | — | |
|
| 22 | 90453-KRM-840 | WASHER, SPLINE (20MM) | 1 шт. | — | |
|
| 23 | 90459-107-000 | WASHER, THRUST (12MM) | 1 шт. | — | |
|
| 24 | 90601-KRM-840 | CIRCLIP (17MM) | 1 шт. | — | |
|
| 25 | 90605-KVS-900 | SET-RING (20MM) | 1 шт. | — | |
|
| 26 | 91003-K1M-T01 | BEARING, RADIAL BALL (15X42X11) | 1 шт. | — | |
|
| 27 | 91013-KSS-901 | BEARING, RADIAL BALL (6001) | 1 шт. | — | |
|
| 28 | 91013-KZV-J01 | BEARING, RADIAL BALL (6001) | 1 шт. | — | |
|
| 29 | 96100-60010-00 | BEARING, RADIAL BALL (6001) | 1 шт. | — | |
|
| 30 | 91015-KSS-901 | BEARING, RADIAL BALL (6203) | 2 шт. | — | |
|
| 31 | 91015-KZV-J01 | BEARING, RADIAL BALL (6203) (NA USE ALT:96100-62030-00) | 0 шт. | — | |
|
| 32 | 91204-KPH-902 | OIL SEAL (17X30X5) (NOK) | 1 шт. | — | |
|
| 33 | 92101-06010-0A | BOLT, HEX. (6X10) | 2 шт. | — | |
|
| 34 | 95701-06014-00 | BOLT, FLANGE (6X14) (Honda Code 2410884) | 2 шт. | — | |
|
