| 1 | 40535-KCR-305 | MASTER LINK SET (SEAL TYPE) (DAIDO) | 1 шт. | — | |
|
| 2 | 40535-KCR-306 | MASTER LINK SET (SEAL TYPE) (RK EXCEL) | 1 шт. | — | |
|
| 3 | 40540-KCR-305 | CHAIN, DRIVE (DID520V6-120ZB) (DAIDO) (STANDARD LINK 110L) | 1 шт. | — | |
|
| 4 | 40540-KCR-306 | CHAIN, DRIVE (RK EXCEL) (RK520SMOZ2-120LJ-FZ) (STANDARD LINK 110L) | 1 шт. | — | |
|
| 5 | 52101-K99-A00 | BOLT, SWINGARM PIVOT | 1 шт. | — | |
|
| 6 | 52141-K99-A00 | COLLAR, PIVOT DISTANCE CENTER | 1 шт. | — | |
|
| 7 | 52144-356-005 | CAP, SWINGARM DUST SEAL (NOK) | 2 шт. | — | |
|
| 8 | 52146-KPS-900 | GUIDE, CHAIN | 1 шт. | — | |
|
| 9 | 52147-MN1-670 | SLIDER, CHAIN GUIDE | 1 шт. | — | |
|
| 10 | 52170-K99-A00 | SLIDER, CHAIN | 1 шт. | — | |
|
| 11 | 52171-KR6-000 | WASHER, CHAIN SLIDER | 2 шт. | — | |
|
| 12 | 52175-KPS-900 | ROLLER, CHAIN (UPPER) | 1 шт. | — | |
|
| 13 | 52200-K99-A00 | SWINGARM SUB-ASSY., RR. | 1 шт. | — | |
|
| 14 | 90103-MY6-670 | BOLT, FLANGE (6X16) | 2 шт. | — | |
|
| 15 | 90115-KPS-900 | SCREW, PAN (5X8) | 2 шт. | — | |
|
| 16 | 90128-KPE-900 | BOLT, SOCKET (12X64) | 1 шт. | — | |
|
| 17 | 90301-KGH-901 | NUT, U (6MM) (FUJI SEIMITSU) | 2 шт. | — | |
|
| 18 | 90305-GE8-003 | NUT, U (14MM) | 1 шт. | — | |
|
| 19 | 90305-KCJ-951 | NUT, U (14MM) (FUJI SEIMITSU) | 1 шт. | — | |
|
| 20 | 90306-KF0-003 | NUT, FLANGE (12MM) (FUSE RASHI) | 1 шт. | — | |
|
| 21 | 90306-KGH-901 | NUT, U (12MM) (FUJI SEIMITSU) | 1 шт. | — | |
|
| 22 | 91070-GC4-601 | BEARING, NEEDLE (20X26X20) (TOYO) BEARING, SWINGARM PIVOT | 2 шт. | — | |
|
| 23 | 91070-KPE-901 | BEARING, NEEDLE (20X26X20) | 2 шт. | — | |
|
| 24 | 93600-06045-0A | SCREW, FLAT (6X45) | 2 шт. | — | |
|
| 25 | 94102-08000 | WASHER, PLAIN (8MM) | 1 шт. | — | |
|
| 26 | 94201-20150 | PIN, COTTER (2.0X15) | 1 шт. | — | |
|
