| 1 | 40510-K87-A00 | CASE, DRIVE CHAIN | 1 шт. | — | |
|
| 2 | 40510-K87-A01 | CASE, DRIVE CHAIN | 1 шт. | — | |
|
| 3 | 40531-K87-A01 | MASTER LINK (RK) | 1 шт. | — | |
|
| 4 | 40545-KYJ-902 | MASTER LINK (DAIDO) | 1 шт. | — | |
|
| 5 | 40540-KYJ-902 | CHAIN, DRIVE (DID520VF-120ZB) (DAIDO) (STANDARD LINK 108L) | 1 шт. | — | |
|
| 6 | 40540-K87-A02 | CHAIN, DRIVE (RK520KLO2-120LJFZ) (RK) (STANDARD LINK 110L) | 1 шт. | — | |
|
| 7 | 40542-K87-A00 | BOLT, CHAIN ADJUSTING | 2 шт. | — | |
|
| 8 | 40543-K87-A00 | ADJUSTER, CHAIN | 2 шт. | — | |
|
| 9 | 40546-K87-A00 | CAP, SWINGARM END | 2 шт. | — | |
|
| 10 | 52101-K87-A00 | BOLT, SWINGARM PIVOT | 1 шт. | — | |
|
| 11 | 52105-K87-A00 | COLLAR B, SWINGARM PIVOT | 1 шт. | — | |
|
| 12 | 52106-KYJ-900 | COLLAR, PIVOT | 1 шт. | — | |
|
| 13 | 52109-K87-A00 | BOLT, PIVOT ADJUSTING | 1 шт. | — | |
|
| 14 | 52141-K87-A00 | COLLAR, PIVOT DISTANCE | 1 шт. | — | |
|
| 15 | 52170-K87-A00 | SLIDER, CHAIN | 1 шт. | — | |
|
| 16 | 52200-K87-A00 | SWINGARM SUB-ASSY., RR. | 1 шт. | — | |
|
| 17 | 90115-MGZ-J00 | SCREW, SPECIAL (6X14) | 2 шт. | — | |
|
| 18 | 90301-K87-A01 | NUT, U (10MM) | 2 шт. | — | |
|
| 19 | 90302-K87-A00 | NUT, LOCK (26X1.5) | 1 шт. | — | |
|
| 20 | 90305-KCJ-951 | NUT, U (14MM) (FUJI SEIMITSU) | 1 шт. | — | |
|
| 21 | 90651-K87-A00 | CIRCLIP (INNER) (20) | 2 шт. | — | |
|
| 22 | 90683-MBW-003 | CLIP, BODY | 1 шт. | — | |
|
| 23 | 91071-MJ0-003 | BEARING, NEEDLE (22X29X30) (NTN) | 1 шт. | — | |
|
| 24 | 91071-MJ0-004 | BEARING, NEEDLE (THOMPSON) | 1 шт. | — | |
|
| 25 | 91213-MB2-003 | DUST SEAL (22X35X7) (ARAI) | 1 шт. | — | |
|
| 26 | 91213-MB2-006 | DUST SEAL (22X35X7) (NOK) | 1 шт. | — | |
|
| 27 | 91283-ML7-003 | DUST SEAL (22X29X4) (ARAI) | 1 шт. | — | |
|
| 28 | 94101-10700 | WASHER, PLAIN (10MM) | 2 шт. | — | |
|
| 29 | 94520-35000 | CIRCLIP (INNER) (35MM) | 1 шт. | — | |
|
| 30 | 96100-62020-10 | BEARING, RADIAL BALL (6202) | 1 шт. | — | |
|
