| 1 | 17211-KYK-D10 | ELEMENT, AIR CLEANER | 1 шт. | — | |
|
| 2 | 17213-KYK-D10 | SEAL, AIR CLEANER COVER | 1 шт. | — | |
|
| 3 | 17215-KYK-D10 | DUCT, AIR CLEANER | 1 шт. | — | |
|
| 4 | 17220-KYK-D10 | COVER, AIR CLEANER | 1 шт. | — | |
|
| 5 | 17223-KVX-600 | COLLAR, AIR CLEANER | 1 шт. | — | |
|
| 6 | 17225-KYK-D10 | CASE SUB-ASSY., AIR CLEANER | 1 шт. | — | |
|
| 7 | 17227-KYY-900 | TUBE, VINYL (11X15X40) | 1 шт. | — | |
|
| 8 | 17236-K99-A00 | PLUG, AIR CLEANER DRAIN | 1 шт. | — | |
|
| 9 | 17250-KYK-D10 | HOLDER, ELEMENT | 1 шт. | — | |
|
| 10 | 17253-KYK-D10 | TUBE, AIR CLEANER CONNECTING | 1 шт. | — | |
|
| 11 | 17256-K94-T00 | BAND, AIR CLEANER CONNECTING TUBE (44) | 1 шт. | — | |
|
| 12 | 17261-KYK-D10 | PLATE, ELEMENT SETTING | 1 шт. | — | |
|
| 13 | 17316-KRH-900 | CLIP, BREATHER TUBE | 1 шт. | — | |
|
| 14 | 17371-KYK-D10 | TUBE, BREATHER | 1 шт. | — | |
|
| 15 | 17390-KYK-D10 | WASHER, TONGUED | 2 шт. | — | |
|
| 16 | 90116-KVB-900 | BOLT, FLANGE (6MM) | 2 шт. | — | |
|
| 17 | 90311-KSH-900 | NUT, CLIP (6MM) | 1 шт. | — | |
|
| 18 | 91406-KVX-600 | CLAMP, TUBE (D14.5) | 1 шт. | — | |
|
| 19 | 93401-05014-07 | BOLT-WASHER (5X14) | 4 шт. | — | |
|
| 20 | 93892-05010-08 | SCREW-WASHER (5X10) | 2 шт. | — | |
|
| 21 | 95002-80000 | CLIP, TUBE (C12) | 2 шт. | — | |
|
| 22 | 95701-06016-00 | BOLT, FLANGE (6X16) (Honda Code 2410892) | 1 шт. | — | |
|
