| 1 | 24211-K99-A00 | FORK, R. GEARSHIFT | 1 шт. | — | |
|
| 2 | 24212-K99-A00 | FORK, CENTER GEARSHIFT | 1 шт. | — | |
|
| 3 | 24213-K99-A00 | FORK, L. GEARSHIFT | 1 шт. | — | |
|
| 4 | 24301-K99-A00 | DRUM, GEARSHIFT | 1 шт. | — | |
|
| 5 | 24321-KYJ-900 | SHAFT, GEARSHIFT FORK | 1 шт. | — | |
|
| 6 | 24410-KSP-860 | PLATE, GEARSHIFT DRUM STOPPER (NA USE ALT:24410-KVS-900) | 0 шт. | — | |
|
| 7 | 24430-KRM-B10 | STOPPER, GEARSHIFT DRUM | 1 шт. | — | |
|
| 8 | 24430-KTT-900 | STOPPER, GEARSHIFT DRUM | 1 шт. | — | |
|
| 9 | 24435-K31-900 | SPRING, DRUM STOPPER | 1 шт. | — | |
|
| 10 | 24610-K31-900 | SPINDLE, GEARSHIFT | 1 шт. | — | |
|
| 11 | 24651-KRM-840 | SPRING, GEARSHIFT RETURN | 1 шт. | — | |
|
| 12 | 24652-KRM-840 | PIN, SHIFT RETURN SPRING | 1 шт. | — | |
|
| 13 | 90003-KVS-900 | BOLT, HEX. (6X20) | 1 шт. | — | |
|
| 14 | 90022-KRM-840 | PIVOT, SHIFT DRUM STOPPER ARM | 1 шт. | — | |
|
| 15 | 90417-KRM-840 | WASHER, DRUM STOPPER | 1 шт. | — | |
|
| 16 | 90417-360-000 | WASHER, DRUM STOPPER | 1 шт. | — | |
|
| 17 | 90457-KRM-840 | WASHER (14MM) | 1 шт. | — | |
|
| 18 | 90606-KRM-840 | CIRCLIP (OUTER) (14MM) | 1 шт. | — | |
|
| 19 | 94510-14000 | CIRCLIP (OUTER) (14MM) | 1 шт. | — | |
|
| 20 | 91009-K31-901 | BEARING, RADIAL BALL (6905) (NSK) | 1 шт. | — | |
|
| 21 | 91112-KRH-900 | ROLLER (3X8.5) | 2 шт. | — | |
|
| 22 | 91203-KSP-911 | OIL SEAL (14X22X5) (ARAI) | 1 шт. | — | |
|
