| 1 | 06420-K99-A00 | SPOKE SET B, RR. (R. SIDE) | 18 шт. | — | |
|
| 2 | 06421-K99-A00 | SPOKE SET A, RR. (L. SIDE) | 18 шт. | — | |
|
| 3 | 40544-KPS-730 | ADJUSTER, R. CHAIN | 1 шт. | — | |
|
| 4 | 40545-KPS-730 | ADJUSTER, L. CHAIN | 1 шт. | — | |
|
| 5 | 41201-KPS-900 | SPROCKET, FINAL DRIVEN (50T) | 1 шт. | — | |
|
| 6 | 42301-K99-A00 | AXLE, RR. WHEEL | 1 шт. | — | |
|
| 7 | 42312-K99-A00 | COLLAR, L. RR. WHEEL | 1 шт. | — | |
|
| 8 | 42312-MCG-000 | COLLAR, R. RR. WHEEL SIDE | 1 шт. | — | |
|
| 9 | 42620-K99-A00 | COLLAR, RR. AXLE DISTANCE | 1 шт. | — | |
|
| 10 | 42635-K99-A00 | HUB SUB-ASSY., RR. | 1 шт. | — | |
|
| 11 | 42650-K99-A00 | WHEEL SUB-ASSY., RR. | 1 шт. | — | |
|
| 12 | 42701-K99-A01 | RIM, RR. WHEEL | 1 шт. | — | |
|
| 13 | 42711-K99-A02 | TIRE, RR. (PIRELLI) (100/100-18 59R N.H.S) | 1 шт. | — | |
|
| 14 | 42712-KHA-941 | TUBE, TIRE (MD-18) (PIRELLI) | 1 шт. | — | |
|
| 15 | 42713-KW8-901 | FLAP, TIRE (1.85-18) (PIRELLI) | 0 шт. | — | |
|
| 16 | 42714-KA3-710 | CAP, VALVE | 1 шт. | — | |
|
| 17 | 42715-KA2-680 | STOPPER, BEAD (1.85) STOPPER, BEAD (1.85B) | 1 шт. | — | |
|
| 18 | 43351-K99-A01 | DISK, RR. BRAKE | 1 шт. | — | |
|
| 19 | 90105-MK5-010 | BOLT, DISK (8X22) | 4 шт. | — | |
|
| 20 | 90125-KA4-000 | SCREW, FLAT (8X31) | 6 шт. | — | |
|
| 21 | 90306-KCJ-951 | NUT, U (16MM) | 1 шт. | — | |
|
| 22 | 90305-ME5-003 | NUT, FLANGE (16MM) | 1 шт. | — | |
|
| 23 | 90309-ML3-791 | NUT, U (8MM) (FUSE RASHI) | 6 шт. | — | |
|
| 24 | 90309-KPH-971 | NUT, U (8MM) (FUJI SEIMITSU) | 6 шт. | — | |
|
| 25 | 90465-MC4-000 | WASHER (8MM) | 6 шт. | — | |
|
| 26 | 91013-KPS-731 | BEARING, RADIAL BALL (6203U) (FUJIKOSHI) | 1 шт. | — | |
|
| 27 | 91013-KPS-732 | BEARING, RADIAL BALL (6203U) (NSK) | 1 шт. | — | |
|
| 28 | 96140-62030-10 | BEARING, RADIAL BALL (6203U) | 1 шт. | — | |
|
| 29 | 91051-KPS-731 | BEARING, RADIAL BALL (6303U) (NACHI) (NA USE ALT:91051-KPS-732) | 0 шт. | — | |
|
| 30 | 91051-KPS-732 | BEARING, RADIAL BALL (6303U) (NSK) | 1 шт. | — | |
|
| 31 | 96140-63030-10 | BEARING, RADIAL BALL (6303U) BEARING, RADIAL BALL (6303) | 1 шт. | — | |
|
| 32 | 91252-KCY-671 | OIL SEAL (25X40X7) | 1 шт. | — | |
|
| 33 | 91252-MC4-005 | OIL SEAL (28X47X2X7) (NOK) | 1 шт. | — | |
|
| 34 | 91252-MC4-013 | OIL SEAL (28X47.2X7) (ARAI) | 1 шт. | — | |
|
| 35 | 94001-08000-0S | NUT, HEX. (8MM) | 1 шт. | — | |
|
| 36 | 94111-08000 | WASHER, SPRING (8MM) | 1 шт. | — | |
|
